Product Description:
These plate cylinder seal kits are precisely engineered replacement sets created for the maintenance and overhaul of MU series compact plate cylinders and pin clamp cylinders. They are available for bore sizes ranging from 25mm to 63mm. Each kit comprises all the essential sealing components needed for a full cylinder rebuild, including the piston seal, rod seal, and bumper.
The seals are made from premium-quality NBR (nitrile rubber) used in the piston and rod seals, while the bumper is crafted from durable urethane. This combination provides excellent resistance to wear, compression set, and the typical pneumatic media encountered in operation. The MU series plate cylinders utilize an oval-shaped piston design, which inherently prevents rotation without requiring a rod with flats. This design enhancement results in longer bearing and seal life.
Regular replacement of seals using these kits helps to restore the cylinder’s optimal performance, prevent air leakage, and extend the service life of the existing actuators. This maintenance approach is highly cost-effective compared to purchasing new cylinders. Please note that the seal kit does not include a grease pack; it should be purchased separately. The recommended grease pack part number is GR-S-010, which contains 10 grams.
Features:
The complete seal kit includes a piston seal, rod seal, and bumper, providing everything needed for a full cylinder rebuild. This comprehensive set ensures that your cylinder can be restored to optimal performance.
Seal kits are available for various bore sizes, including 25mm, 32mm, 40mm, 50mm, and 63mm, allowing you to choose the perfect fit for your application. The piston and rod seals are made from NBR material, which is known for its excellent wear resistance and ability to withstand compression.
In addition, the kit features a urethane bumper that delivers dependable cushioning at the end of the stroke, protecting the cylinder from impact damage. It is specifically designed to be compatible with MUB and MDUB series compact plate cylinders, ensuring seamless integration.
By preventing air leakage, the seal kit helps restore the cylinder’s force, speed, and sealing performance. It serves as a cost-effective solution compared to replacing the entire cylinder, effectively extending the lifespan of your actuator.
Installation is straightforward and can be completed quickly using standard tools. This makes the seal kit ideal for applications with limited space, such as automated assembly lines, clamping devices, and indexing systems.
Managing inventory is simplified by having one kit number per bore size. Additionally, a grease pack (model GR-S-010, 10g) is available separately to assist with maintenance and ensure optimal operation.
Technical Parameters:
| Bore Sizes |
25mm, 32mm, 40mm, 50mm, 63mm |
| Kit Contents |
Piston Seal, Rod Seal, Bumper |
| Bumper Material |
Urethane |
| Seal Material |
NBR |
| Product Type |
Seal Kit / Repair Kit |
| Series |
MUB / MDUB |
Applications:
Automated Assembly
We provide comprehensive maintenance services for plate cylinders used in precision positioning systems. Ensuring accuracy and reliability is our top priority in automated assembly applications.
Clamping and Indexing Systems
Our expertise includes the repair of cylinders employed in clamping and indexing mechanisms, helping to maintain efficient and accurate operation in various industrial processes.
Material Handling
For compact handling systems, we specialize in replacing seals within cylinders, enhancing their performance and prolonging the service life of material handling equipment.
Packaging Machinery
We perform maintenance on cylinders utilized in packaging and filling machines, ensuring smooth and consistent operation to meet high productivity standards.
Electronic Component Manufacturing
Cylinder repairs in precision assembly equipment are part of our service offerings, supporting the production of electronic components with exacting standards.
General Industrial Pneumatics
Our solutions extend to any industrial application that demands reliable and compact cylinder sealing, delivering dependable pneumatic performance across diverse sectors.
