Compatible SMC Cylinder Overhaul Kit CS1‑250A‑PS / CS2‑250A‑PS Full Wiper And Sealing Spare Parts For High Load Factory Pneumatic Cylinder Replacement Work

Product Description:

These tie rod cylinder seal kits are meticulously engineered replacement sets, specifically designed for the maintenance and overhaul of CS1 series large bore pneumatic cylinders. They cater to bore sizes ranging from 125mm to 300mm, ensuring a comprehensive solution for various cylinder dimensions.

Each kit includes all the essential sealing components needed for a full cylinder rebuild. These components consist of a wiper ring, cushion seal, rod seal, piston seal, valve seal, tube gasket, and retaining plate gasket. Additionally, every seal kit comes with an appropriate grease pack to facilitate proper lubrication during installation. The grease quantity varies by bore size: 40g for 125-160mm, 50g for 180-200mm, and 60g for 250-300mm bores.

The seals are crafted from premium NBR (nitrile rubber), which provides outstanding resistance to wear, oil, and abrasion, guaranteeing reliable performance in pneumatic applications. The CS1 series cylinders feature a square cover and a tie-rod type design, available in bore sizes from 125mm up to 300mm. These cylinders come in both double-acting single rod and double rod configurations and are compatible with standard, lube/non-lube, and air-hydro type operations.

Regular replacement of seals using these kits helps restore the cylinder’s performance, effectively eliminates air leakage, and significantly extends the service life of existing actuators. This maintenance approach offers an economical alternative compared to the cost of entirely replacing the cylinders.

Please note that certain parts such as the piston gasket, guide gasket, and some other components are non-replaceable and therefore are not included in the seal kit.

Features:

The Complete Seal Kit offers a comprehensive set of components for a full cylinder rebuild. Each kit contains essential parts including a wiper ring, cushion seal, rod seal, piston seal, valve seal, tube gasket, and retaining plate gasket, ensuring your cylinder is thoroughly serviced.

Designed to accommodate a wide bore size range, these kits are available for bore sizes of 125mm, 140mm, 160mm, 180mm, 200mm, 250mm, and 300mm. This variety makes it easy to find the perfect fit for your specific pneumatic cylinder requirements.

The seals in the kit are crafted from high-quality nitrile rubber (NBR), known for its excellent resistance to oil and wear. This material choice guarantees durability and reliable performance under demanding conditions.

Compatible specifically with the CS1 and CDS1 series tie rod pneumatic cylinders featuring a square cover design, the kit ensures seamless integration and optimal functionality with these models.

For convenience during installation, each seal kit comes with a grease pack included. This lubrication pack helps maintain proper seal function and enhances the longevity of the rebuilt cylinder.

By replacing worn seals with this kit, users can effectively eliminate air leakage within the cylinder. This restoration improves the original operating force and speed, bringing the actuator's performance back to its intended level.

The seal kits are suitable for both lubricated (lube) and non-lubricated (non-lube) cylinder types, providing versatility across different pneumatic system setups.

Additionally, the kits are compatible with air-hydro type cylinders, specifically for bore sizes 125mm, 140mm, and 160mm, expanding their application in varied pneumatic and hydraulic hybrid systems.

Offering a cost-effective maintenance solution, these seal kits represent only a fraction of the price of a new cylinder. Using them extends the service life of actuators while minimizing downtime and replacement expenses.

The operating temperature range of the seals spans from -10°C to +70°C, making them suitable for various environmental conditions encountered in typical industrial applications.

To simplify inventory management, each bore size is associated with a single kit number, streamlining stocking and reordering processes for maintenance teams.

For those needing additional lubrication options, grease packs are also available separately under the codes GR-S-010 (10g) and GR-S-020 (20g), allowing customization of lubrication quantities as required.
