SMC MKB/MKA16-PS Rotary Clamp Cylinder Seal Repair Kit For 16mm Bore MK Series Rotating Clamping Cylinder NBR Seals For Pneumatic Fixture Maintenance

Product Description:

These rotary clamp cylinder seal kits are meticulously engineered as replacement sets specifically for the maintenance and overhaul of MKA and MKB series pneumatic rotary clamp cylinders. They are available for bore sizes ranging from 16mm to 63mm, ensuring compatibility across a wide range of models. Each kit is equipped with all essential sealing components needed for a thorough cylinder rebuild, including the wiper ring, piston seal, rod seal, valve seal, and tube gasket. Additionally, every seal kit comes with a grease pack to guarantee proper lubrication during installation – 10g for bore sizes between 16mm and 50mm, and 20g for the 63mm bore.

The seals provided in these kits are crafted from high-quality materials to deliver durable and reliable performance. NBR (nitrile rubber) is used for the piston seal, rod seal, valve seal, and tube gasket, known for its excellent resistance to wear, oil, and abrasion. Urethane is utilized for the cushion seal, offering additional durability. These robust materials ensure that the seals can withstand the demanding conditions typical of pneumatic clamping operations.

The MKA and MKB series cylinders are designed to combine both linear and rotary motions, enabling precise and effective clamping in automated systems. They provide consistent and reliable force even within confined spaces, making them ideal for various industrial applications.

Performing regular seal replacements using these kits not only restores the cylinder’s optimal performance but also eliminates air leakage and significantly extends the lifespan of your existing actuators. This maintenance approach is a cost-effective alternative to full cylinder replacement. Please note, however, that the cushion valve seal is a non-replaceable component and is not included within these seal kits.

Features:

The Complete Seal Kit includes every essential component needed for a full cylinder rebuild. Each package contains a wiper ring, piston seal, rod seal, valve seal, and a tube gasket, ensuring a comprehensive solution for maintenance.

It is available in a wide range of bore sizes, including 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm, catering to various application requirements.

Constructed from high-quality materials, the kit features NBR seals known for their excellent oil resistance, along with urethane cushion seals that provide dependable end-of-stroke cushioning performance.

Specifically designed for compatibility with MKA and MKB series rotary clamp cylinders, the seal kits fit MKA models with both ends tapped and MKB models with through-hole basics.

Each kit also includes a grease pack, facilitating proper lubrication during installation and ensuring optimal operation upon assembly.

By replacing worn seals with this kit, users can restore the original clamping force, improve operational speed, and enhance the accuracy of rotary motion.

This maintenance solution is cost-effective, representing only a fraction of the price of purchasing a new cylinder while significantly extending the service life of the actuator.

The design allows for quick and easy installation using standard tools, making the replacement process straightforward and efficient.

Suitable for use within an operating temperature range of -10°C to +70°C, the seals perform reliably under various working conditions.

Inventory management is simplified by having a single kit number for each bore size, streamlining stocking and ordering procedures.

Technical Parameters:

Applications:

Support and Services:

Our Piston Pneumatic Cylinder product is designed for reliable performance and long service life in various industrial applications. For technical support, please ensure you have the model number and specifications of your cylinder ready to help us assist you more efficiently.

We offer a range of services including installation guidance, maintenance tips, troubleshooting assistance, and repair services to keep your pneumatic cylinders operating at peak efficiency. Our technical team can help diagnose issues such as air leakage, loss of pressure, or mechanical wear.

For optimal performance, regular inspection and lubrication of the piston pneumatic cylinder are recommended. Replacement parts and upgrade kits are available to extend the lifespan of your equipment.

We also provide comprehensive documentation, including user manuals, installation instructions, and safety guidelines, to ensure proper use and handling of the product.

Should you require custom solutions or have specific application needs, our engineering team is available to provide expert consultation and support tailored to your requirements.
