MKB/MKA20-PS Service Seal Kit Compatible With SMC MK 20 Bore Rotary Swing Clamp Air Cylinder Full O Rings And Piston Seals For Automation Jig Maintenance

Product Description:

These rotary clamp cylinder seal kits are meticulously engineered replacement sets, specifically designed for the maintenance and complete overhaul of MKA and MKB series pneumatic rotary clamp cylinders. Suitable for bore sizes ranging from 16mm to 63mm, each kit includes all the essential sealing components needed for a thorough cylinder rebuild. The components provided in each kit include a wiper ring, piston seal, rod seal, valve seal, and tube gasket. Additionally, every seal kit comes with a grease pack—10g for bore sizes from 16mm to 50mm, and 20g for the 63mm bore—to ensure proper lubrication during the installation process.

The seals themselves are crafted from premium materials to guarantee durability and effective operation. NBR (nitrile rubber) is used for the piston seal, rod seal, valve seal, and tube gasket, while urethane serves as the material for the cushion seal. These materials are chosen for their excellent resistance to wear, oil, and abrasion, making them highly suitable for demanding pneumatic clamping environments. The MKA and MKB series cylinders uniquely combine linear and rotary motions, providing precise clamping action within automated systems, and delivering consistent force even in confined spaces.

By regularly replacing seals using these kits, users can restore the cylinder's optimal performance, prevent air leaks, and significantly extend the service life of existing actuators, all at a much lower cost compared to full replacements. It is important to note, however, that the cushion valve seal is a non-replaceable component and therefore is not included in these seal kits.

Features:

This comprehensive seal kit contains all necessary components for a full cylinder overhaul. Included are the wiper ring, piston seal, rod seal, valve seal, and tube gasket, ensuring a complete rebuild of your cylinder.

The kit is available in various bore sizes to accommodate different applications. Options include 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm, providing flexibility for a variety of cylinder specifications.

Seals are crafted from high-quality NBR and urethane materials. The NBR seals deliver excellent resistance to oil, while the urethane cushion seal offers dependable cushioning at the end of the stroke to protect the cylinder and enhance performance.

This seal kit is specifically designed for use with MKA series cylinders, featuring tapped ends, and MKB series cylinders, which are through-hole basics. It ensures a perfect fit and reliable operation for these rotary clamp cylinders.

Each kit comes with a grease pack to facilitate correct lubrication during installation. This helps maintain seal integrity and contributes to smooth, long-lasting operation.

Replacing worn or damaged seals with this kit helps restore the cylinder’s original clamping force, speed, and rotary motion accuracy, effectively extending the service life and reliability of your equipment.

Choosing this seal kit for maintenance is a budget-friendly alternative to purchasing a new cylinder, offering significant cost savings while ensuring optimal performance.

The kit is designed for quick and straightforward installation using standard tools, minimizing downtime and simplifying maintenance procedures.

Seals in this kit perform reliably within a temperature range from -10°C to +70°C, making them suitable for various working environments.

Each bore size corresponds to a single kit number, streamlining inventory control and ordering processes for maintenance teams.

Technical Parameters:

Applications:

Support and Services:

Our Piston Pneumatic Cylinder product is designed for reliable and efficient performance in various industrial applications. For technical support and service inquiries, we provide comprehensive assistance including troubleshooting, maintenance guidelines, and replacement part information.

We recommend regular inspection and lubrication to ensure optimal operation and to extend the lifespan of your pneumatic cylinder. In case of any operational issues, please refer to the product manual for step-by-step troubleshooting procedures.

Our technical support team is equipped to help with installation advice, performance optimization, and compatibility questions to ensure that the piston pneumatic cylinder meets your specific application requirements.

For service requests, including repairs or part replacements, please have your product model number and purchase details ready to facilitate prompt and efficient support.

We are committed to providing high-quality support and services to maximize the performance and durability of your piston pneumatic cylinder.
