Product Description:
The Norgren F17 and F18 series are high flow, general-purpose compressed air filters engineered to eliminate liquid water and solid contaminants from pneumatic systems. These filters play a critical role in safeguarding downstream air-operated components such as valves, cylinders, and tools, preventing corrosion and potential damage.
The F17 series accommodates port sizes ranging from G3/4 to G1-1/4 and supports flow rates up to 236 dm³/s (500 SCFM). In comparison, the F18 series is designed for larger port sizes, specifically G1-1/2 and G2, with flow capacities reaching up to 765 dm³/s. Both series operate at a maximum inlet pressure of 17 bar and can function effectively within a temperature range of -20°C to +80°C.
Equipped with sintered polypropylene filter elements available in either 40 μm or 5 μm options, these filters provide efficient particulate removal suitable for a broad spectrum of industrial applications. Users can choose between manual 1/4-turn drains or automatic drain configurations to meet varying maintenance preferences.
The filters feature an aluminium alloy bowl integrated with a highly visible prismatic liquid level indicator lens, which simplifies monitoring of condensate accumulation. Additionally, the screw-on bowl design allows for hassle-free servicing without the need for tools or disconnecting the unit from the air line.
Features:
High Flow Capacity
The F17 series offers flow rates up to 236 dm³/s (500 SCFM), while the F18 series can handle higher volumes, reaching up to 765 dm³/s. These capacities make the series ideal for demanding applications that require large flow rates.
Filtration Options
Two filtration grades are available to suit different needs: 40 μm and 5 μm sintered polypropylene elements. These filters efficiently remove particulate contaminants to ensure clean air supply.
Drain Configurations
Users can choose between manual and automatic drain options. The manual drain features a convenient 1/4-turn mechanism, while the automatic drain offers hands-free operation for continuous maintenance.
Durable Aluminium Alloy Bowl
The unit is equipped with a sturdy aluminium alloy bowl that includes a sight glass and a prismatic liquid level indicator lens, providing highly visible monitoring of fluid levels.
Tool-Free Maintenance
The screw-on bowl design enables servicing without the need for tools or detaching the unit from the air line. This feature significantly reduces maintenance time and effort.
High Pressure Compatibility
Designed for high-pressure pneumatic systems, these filters can operate at a maximum inlet pressure of 17 bar (247 psi), ensuring reliable performance under demanding conditions.
Wide Operating Temperature Range
The filters maintain effective operation across a broad temperature range, from -20°C to +80°C, making them suitable for a variety of environmental conditions.
Reliable Sealing
Standard Nitrile Rubber (NBR) seals provide dependable sealing performance, helping to prevent leaks and maintain system integrity.
Effective Contaminant Removal
The filters are capable of removing both liquid and solid contaminants, protecting air-operated devices from damage caused by water, oil, and particulates.
Multiple Port Sizes
The F17 series offers port sizes of G3/4, G1, and G1-1/4, while the F18 series provides larger options including G1-1/2 and G2. This variety allows compatibility with different system requirements.
Lightweight and Corrosion-Resistant Body
The aluminium alloy body not only reduces overall weight but also offers excellent corrosion resistance, enhancing durability and longevity.
Technical Parameters:
| Operating Temperature |
-20°C To +80°C |
| Port Sizes |
G3/4, G1, G1-1/4, G1-1/2, G2 |
| Elastomers |
NBR |
| Body Material |
Aluminium Alloy |
| Drain Types |
Manual (1/4 Turn), Automatic |
| Filtration Grades |
40 μm, 5 μm |
Applications:
Industrial Automation
Ensuring a clean air supply is essential for the proper functioning of pneumatic actuators, valves, and cylinders used in manufacturing and assembly lines. Maintaining air purity helps enhance equipment performance and longevity.
Packaging Machinery
Pneumatic components within packaging and filling equipment require protection to operate efficiently. Effective air filtration safeguards these components from contaminants, ensuring smooth and reliable packaging processes.
Material Handling
Air filtration plays a crucial role in conveyors, pick-and-place units, and other handling systems. Clean air is vital to maintain precision and reduce downtime in material handling operations.
Compressed Air Distribution
For applications demanding large air flow, point-of-use filtration is necessary. This ensures that compressed air delivered at various points remains free of impurities, supporting system efficiency and equipment protection.
Automotive Manufacturing
Air preparation is a critical factor in automotive paint shops, assembly lines, and testing equipment. Proper filtration ensures consistent air quality, contributing to product quality and operational reliability.
Steel and Metallurgy
Industrial environments in steel and metallurgy require robust and dependable air filtration solutions. These systems must withstand demanding conditions while providing clean air to support various pneumatic applications.
General Industrial Pneumatics
Any industrial application that demands clean, dry compressed air with high flow capacity benefits from advanced filtration technology. This ensures optimal performance and reduces maintenance needs across a wide range of pneumatic systems.
Customization:
The Norgren Pneumatic Filter Regulator Lubricator, model number F17-600-M3HG, is a high-quality Pressure Reducer designed to optimize your pneumatic systems. Manufactured in China and certified with CE, this product ensures reliable performance and safety.
We offer product customization services tailored to your specific needs. You can choose between manual (1/4 turn) or automatic drain types, filtration grades of 40 μm or 5 μm, and a wide range of port sizes including G3/4, G1, G1-1/4, G1-1/2, and G2. The elastomers used are NBR, suitable for operating temperatures from -20°C to +80°C.
Our Pneumatic Filter Regulator Lubricator is compatible with FESTO air source treatment units, making it an excellent choice for integrating into existing FESTO systems. Whether you require a single unit or bulk orders up to 5000 pieces per month, we can accommodate your demand with a minimum order quantity of just 1.
Packaging is customizable according to client requirements, typically using cartons for secure transport. Delivery time ranges from 1 to 7 work days after payment, with flexible payment terms including T/T, Western Union, and Paypal. Pricing is negotiable to ensure the best value for your investment.
Trust Norgren for premium pneumatic solutions that enhance your FESTO air source treatment unit setups and ensure efficient pressure reduction in your applications.
Packing and Shipping:
Product Packaging: The Pneumatic Filter Regulator Lubricator is securely packaged in a durable, corrugated cardboard box designed to protect the unit from damage during transit. Inside the box, the product is cushioned with foam inserts to prevent movement and absorb shocks. Each unit is individually wrapped in anti-static plastic to protect against dust and moisture. The packaging also includes an instruction manual and warranty card.
Shipping Information: The product is shipped via reliable courier services with tracking options available. Standard shipping ensures delivery within 5-7 business days, while expedited shipping options are available for faster delivery. Each package is clearly labeled with handling instructions and the recipient’s address to ensure safe and accurate delivery. International shipping is supported with proper customs documentation included.
