Product Description:
The Norgren B07 and B68G series consist of integrated filter regulator units designed to combine filtration and pressure regulation within a single, compact enclosure. These units effectively eliminate liquid water and solid contaminants from compressed air lines, while ensuring accurate control of downstream pressure.
The B07 series is a range of miniature filter regulators tailored for installations where space is limited. It features a durable zinc alloy body and a transparent polycarbonate bowl that offers 360-degree visibility. Additionally, the series includes a non-rising adjustment knob equipped with snap-action locking for convenient and reliable pressure setting. The B07 units come with G1/8 and G1/4 port sizes, supporting flow rates up to 24 SCFM (11 dm³/s). Their outlet pressure can be adjusted within the ranges of 0.3 to 7 bar or 0.3 to 10 bar.
On the other hand, the B68G series belongs to the Olympian Plus plug-in system, which facilitates rapid modular installation and removal. These units are constructed with an aluminium body and a matching aluminium bowl featuring a prismatic liquid level indicator. Port sizes available include G3/4, G1, and G1-1/2. The B68G series accommodates significantly higher flow rates, up to 440 SCFM (207.7 dm³/s), with an outlet pressure adjustment range from 0.4 to 8 bar and a maximum inlet pressure rating of 17 bar.
Features:
Integrated Filter and Regulator
This device combines particulate filtration and pressure regulation within a single compact unit, effectively saving valuable installation space without compromising performance.
Filtration Options
It offers two filtration grades, featuring either 5 µm or 40 µm sintered polypropylene filter elements. These options ensure efficient removal of contaminants to protect your pneumatic systems.
Drain Configurations
Users can select between manual or automatic drain options, providing convenient methods for condensate removal based on specific application requirements.
Visual Monitoring Features
The transparent polycarbonate bowl (B07) provides 360° visibility of condensate levels, allowing for easy and reliable monitoring. Alternatively, the aluminium bowl with a prismatic liquid level indicator lens (B68G) offers enhanced durability suited for harsh environmental conditions.
User-Friendly Adjustments
Equipped with a non-rising adjusting knob featuring a snap-action locking mechanism, the regulator prevents accidental pressure changes, ensuring stable and safe operation.
Pressure Relief Design
The relieving design enables downstream pressure reduction when the system is dead-ended, maintaining system balance and safety.
Compact and Modular Design
The B07 model boasts a compact miniature form factor ideal for tight spaces in small pneumatic systems. Meanwhile, the B68G model features the Olympian Plus plug-in system, allowing quick modular installation and removal, facilitating easy maintenance and future system expansion.
Performance Specifications
The B68G model supports a high flow capacity of up to 440 SCFM, suitable for demanding large flow applications. Maximum inlet pressures are 10 bar for the B07 and 17 bar for the B68G. Temperature ranges vary by model, with the B07 operating between -34°C and +50°C, and the B68G between -20°C and +80°C.
Additional Features
Full flow gauge ports are incorporated to allow pressure monitoring without restricting airflow, enhancing operational efficiency and convenience.
Technical Parameters:
| Drain Types |
Manual, Automatic |
| Elastomers |
Nitrile, Synthetic Rubber |
| Gauge Port |
Rc 1/8 |
| Bowl Material |
Polycarbonate, Aluminium |
| Filtration Grades |
5 µm, 40 µm |
| Operating Temperature |
-34°C To +50°C |
| Port Sizes |
G1/8, G1/4, G3/4, G1, G1-1/2 |
| Body Material |
Zinc Alloy, Aluminium |
Applications:
Industrial Automation
In the realm of industrial automation, it is crucial to provide a clean and well-regulated air supply. This ensures the optimal performance of pneumatic actuators, valves, and cylinders used in various automated processes.
Packaging Machinery
Pneumatic components in packaging and filling equipment require effective protection. Proper air treatment helps maintain the reliability and longevity of these components by preventing contamination and regulating pressure.
Material Handling
Air preparation plays a vital role in the operation of conveyors, pick-and-place units, and other handling systems. Ensuring clean and controlled air supply enhances the efficiency and precision of these material handling processes.
Compressed Air Distribution
At the point of use, filtration and regulation of compressed air are essential for tools and equipment. This localized air treatment guarantees consistent performance and protects the machinery from damage caused by impurities or incorrect pressure levels.
General Pneumatic Systems
In manufacturing facilities, the removal of contaminants and the control of pressure are fundamental to maintaining effective pneumatic systems. Clean air and proper regulation prevent downtime and extend the life of pneumatic devices.
Textile Machinery
Textile production relies on pneumatic controls that require clean, filtered, and regulated air. Proper air preparation supports the smooth operation of textile machinery and ensures product quality.
Automotive Manufacturing
In automotive manufacturing, air preparation is critical in various areas such as paint shops, assembly lines, and testing equipment. Clean and regulated compressed air contributes to high-quality finishes and precise assembly processes.
Support and Services:
Our Pneumatic Filter Regulator Lubricator (FRL) units are designed to ensure optimal performance and longevity of your pneumatic systems by providing clean, regulated, and lubricated air supply. For technical support, please refer to the product manual for installation guidelines, maintenance procedures, and troubleshooting tips.
Regular maintenance of the FRL unit includes checking and replacing filter elements, draining accumulated water from the bowl, and replenishing the lubricator with the appropriate oil. Ensure that the air pressure settings are within the recommended range specified in the product documentation to avoid damage or suboptimal operation.
If you experience issues such as pressure drops, air leaks, or inadequate lubrication, verify all connections and inspect the unit for wear or damage. Replacement parts and accessories are available to maintain the unit's performance.
Our technical support team is committed to assisting you with product selection, installation advice, and resolving any operational challenges you may encounter. For further assistance, please consult the detailed FAQ section or product resources available on our website.
Packing and Shipping:
Product Packaging: The Pneumatic Filter Regulator Lubricator is securely packaged to ensure protection during transit. Each unit is individually wrapped in anti-static foam and placed inside a sturdy cardboard box. The packaging includes clear labeling with product details, handling instructions, and safety warnings to ensure proper care. Multiple units are packed in a larger carton with cushioning materials to prevent movement and damage.
Shipping: The product is shipped via reliable courier services with tracking options available. Shipping methods include standard, expedited, and freight options depending on order size and destination. All shipments are carefully inspected before dispatch to guarantee quality and completeness. International shipping is supported with appropriate customs documentation to facilitate smooth delivery.
