270° Adjustable Angle Double-Acting Rotary Vane Pneumatic Swing Cylinder Semi-Rotary Actuator Size 40

Product Description:

The FESTO DSM series is a double-acting vane type semi-rotary actuator designed to deliver precise angular rotation. It operates by driving the rotary vane using compressed air, allowing for smooth and controlled motion.

The actuator offers an infinitely adjustable swivel angle within its full range, which can reach up to 270°. It is equipped with fixed metal stops to ensure high positioning accuracy during operation, enhancing reliability in various applications.

There are multiple options available for cushioning, shaft types, and mounting styles, providing flexibility to meet specific requirements. Its modular structure also supports position sensing through proximity switches, making it adaptable for automated systems.

Certain models within the DSM series comply with the ATEX explosion-proof standard, making them suitable for use in hazardous environments. Additionally, the tandem vane variant is capable of delivering higher torque, up to 80 Nm, for demanding tasks.

With its compact design and features like splash-proof and dust-proof construction, the DSM series is widely utilized for functions such as rotating, flipping, indexing, and positioning in automated production lines, contributing to efficient and reliable manufacturing processes.

Features:

The vane features a double-acting structure, allowing for an infinitely adjustable swivel angle throughout the entire range. This design enables easy and precise fine-tuning of the angle to meet specific requirements.

A fixed metal stop is incorporated to ensure that the stop position remains stable even under load. This provides excellent repeat positioning accuracy, ensuring consistent performance during operation.

There are several cushioning options available to accommodate various impact loads. These include elastic cushions, adjustable elastic cushions, and hydraulic shock absorbers, each designed to provide optimal cushioning based on different application needs.

Technical Parameters:

Applications:

Automated assembly lines incorporate various functions such as workpiece flipping, fixture rotation, and station indexing to enhance the efficiency and accuracy of production processes.

In the realm of material handling, rotary grippers on manipulators and diverting mechanisms play a crucial role in sorting and transporting items seamlessly within a facility.

The packaging industry relies on precise operations including cap screwing, material redirection, and accurate carton positioning to ensure product integrity and streamlined packaging workflows.

Machine tools and processing equipment benefit significantly from features like jig rotation and angle switching of clamping units, which provide flexibility and precision in manufacturing tasks.

Robotics applications often involve the use of small rotary joints and angular positioning systems to achieve delicate and exact movements required in complex robotic functions.

In automotive automation, key processes such as parts clamping and rotation, along with swing motions for test stations, are vital for maintaining high standards of assembly and quality control.

Light industry automation utilizes components like conveyor stoppers, direction changers, and material sorting mechanisms to optimize production lines and ensure smooth material flow.
