270° Swivel Angle Double-Acting Rotary Vane Cylinder Size 12 Semi Rotary Actuator for Automated Assembly Indexing

Product Description:

The FESTO DSM series is a double-acting vane type semi-rotary actuator designed for precise angular rotation. It operates by using compressed air to drive the rotary vane, enabling smooth and controlled motion. The swivel angle can be infinitely adjusted throughout its full range, which extends up to 270 degrees.

This series is equipped with fixed metal stops that ensure high positioning accuracy during operation. Users can choose from multiple cushioning options, various shaft types, and mounting styles to best suit their specific applications. Its modular design also supports position sensing through the integration of proximity switches.

Certain models in the DSM series meet the ATEX explosion-proof standard, making them suitable for use in hazardous environments. Additionally, the tandem vane variant provides an increased torque capacity of up to 80 Nm, catering to more demanding tasks.

Featuring a compact and robust body that is splash-proof and dust-proof, the DSM series is widely utilized in automated production lines for operations such as rotating, flipping, indexing, and precise positioning. Its versatile functionality and durable design make it ideal for various industrial automation needs.

Features:

The vane features a double-acting structure that allows for an infinitely adjustable swivel angle across the entire range. This design makes it easy to perform precise fine angle tuning, enhancing operational flexibility.

Equipped with a fixed metal stop, the stop position remains stable even under load conditions. This ensures excellent repeat positioning accuracy, contributing to reliable and consistent performance.

There are multiple cushioning options available to suit various impact load requirements. These include elastic cushions, adjustable elastic cushions, and hydraulic shock absorbers, providing effective protection and adaptability for different applications.

Technical Parameters:

This Aluminum alloy pneumatic rotary cylinder is designed for versatile applications. The FESTO DSM swing cylinder offers reliable performance with its rotary vane structural design, suitable for ambient temperatures ranging from -10 °C to 60 °C. Its compact size 12 and wide swivel angle of 0° to 270° make it an ideal choice for precise pneumatic rotary motion. The double-acting mode of operation and flexible mounting position further enhance its usability.

Applications:

In automated assembly lines, rotary mechanisms play a crucial role in various tasks such as flipping workpieces, rotating fixtures, and indexing stations. These operations help streamline production processes and improve efficiency.

Material handling systems utilize rotary grippers attached to manipulators as well as diverting mechanisms designed for sorting tasks. These components facilitate the smooth movement and organization of materials within manufacturing environments.

The packaging industry benefits from rotary technology in several ways, including cap screwing, redirecting materials, and positioning cartons accurately. These functions contribute to faster and more reliable packaging operations.

In the realm of machine tools and processing equipment, rotary mechanisms are used for tasks such as jig rotation and angle switching of clamping units. These capabilities enable precise adjustments and improve machining accuracy.

Robotics often incorporate small rotary joints and angular positioning systems which enhance the dexterity and flexibility of robotic arms. This allows robots to perform complex movements with high precision.

Automotive automation involves the clamping and rotation of parts as well as swing motions for test stations. Rotary technology in these applications ensures secure handling and efficient testing processes.

Light industry automation employs rotary components like conveyor stoppers, mechanisms for changing direction, and material sorting systems. These features streamline production lines and optimize workflow in lighter manufacturing sectors.

Support and Services:

Our Piston Pneumatic Cylinder product is designed to deliver reliable and efficient performance in various industrial automation applications. For technical support, please ensure that you have the product model number, specifications, and details of the issue ready when seeking assistance.

We offer comprehensive services including installation guidance, troubleshooting, maintenance advice, and replacement parts support to maximize the lifespan and functionality of your pneumatic cylinder.

For installation, it is important to follow the recommended mounting instructions and ensure proper alignment to prevent premature wear and tear. Regular maintenance should include checking for air leaks, lubrication of moving parts, and inspection of seals.

If you encounter any operational issues such as air leakage, reduced stroke efficiency, or unusual noises, please refer to the troubleshooting section of the product manual or our online resources for step-by-step solutions.

We also provide customization options and technical consultations to help integrate the piston pneumatic cylinder seamlessly into your specific application requirements.

Our technical support team is dedicated to providing prompt and effective solutions to keep your operations running smoothly.
