Dispensing Equipment Pneumatic Valve IMI Norgren VCB22B417A-AB213J G1/4 24VDC 3/2 NC Single Solenoid Spring Return for Precision Fluid Control

Product Description:

The IMI Norgren VCB22 Series represents a high-performance solenoid actuated spool valve designed to deliver various directional control functions, including 3/2, 5/2, and 5/3 configurations. This versatility makes it suitable for a broad spectrum of industrial pneumatic automation tasks. The valve features a compact aluminum housing that incorporates standard LED indicator lights for easy operational status monitoring.

Equipped with an internal pilot air supply, the VCB22 series can handle flow rates ranging from 245 to 3350 liters per minute. This range ensures the valve meets the demands of pneumatic circuits, whether for miniature systems or high-flow applications, providing flexible and reliable control options.

The series offers four different valve widths: 18mm, 22mm, 27mm, and 34mm, accommodating various port sizes including M5, G1/8, G1/4, G3/8, and G1/2. Additionally, NAMUR mounting options are available, enabling seamless integration with sub-base systems to facilitate straightforward manifold assembly and maintenance.

Due to its robust design and adaptability, the VCB22 series is extensively utilized across multiple industries, such as packaging machinery, automotive manufacturing, food and beverage processing, textile equipment, chemical processing, and general industrial automation sectors.

Features:

Experience the trusted quality of authentic IMI Norgren industrial solenoid valves, renowned for their reliability and performance in demanding applications.

These valves are offered in multiple directional control options including 3/2, 5/2, and 5/3 configurations, providing versatile solutions for various pneumatic circuit requirements.

Choose from four valve widths to suit your installation needs: 18mm (Type A), 22mm (Type B), 27mm (Type C), and 34mm (Type D). The valves also feature a wide selection of port sizes, such as M5, G1/8, G1/4, G3/8, and G1/2, plus NAMUR standard ports G1/4 and G3/8.

Designed for high flow capacities ranging from 245 to 3350 liters per minute at 6 bar inlet pressure with a pressure drop of 1 bar, these solenoid valves ensure efficient air flow. Each valve includes a standard LED indicator light that provides a clear visual status of power supply.

The valves incorporate a convenient push-and-turn manual override lock mechanism which facilitates easy commissioning and maintenance. They are rated for 100% continuous duty, making them suitable for extended operation without compromise.

With an IP65 protection rating, these valves are built to withstand harsh industrial environments. The aluminum housing offers a lightweight yet sturdy construction, while NBR seals ensure reliable operation with compressed air.

The sub-base mounting system simplifies piping and allows for manifold assembly. Internal pilot air supply is utilized, eliminating the need for external pilots. Electrical voltage tolerance is ±10%, accommodating typical industrial power fluctuations.

Available in both single solenoid (spring return) and double solenoid versions, the valves also provide three different 5/3 center functions: All Ports Blocked (APB), Center Open Exhaust (COE), and Center Open Pressure (COP), to suit varied operational demands.

Technical Parameters:

Applications:

The Norgren VCB22 series solenoid valves are extensively utilized across a variety of industrial sectors, offering reliable pneumatic control solutions tailored to specific industry needs.

In the packaging machinery industry, these valves are employed for pneumatic actuation control, playing a crucial role in food packaging, carton forming, and filling line processes. Their precise operation ensures efficient and consistent packaging performance.

The automotive manufacturing sector benefits from the VCB22 series by using them for air circuit switching in welding fixtures, assembly lines, and robotic workcells. This enables streamlined production with enhanced control and flexibility.

Within the food and beverage industry, these solenoid valves facilitate automated processes such as filling equipment, labeling machines, and sorting systems, contributing to higher throughput and improved accuracy.

For textile machinery , the valves provide pneumatic drive capabilities for looms, dyeing equipment, and fabric handling lines, supporting smooth and efficient fabric production operations.

In the chemical and pharmaceutical fields, the VCB22 series serves as a means of pneumatic isolation in process control fluid circuits. It is important to verify media compatibility to ensure reliable and safe operation in these sensitive applications.

The electronics and semiconductor industries use these solenoid valves to achieve precise pneumatic control for cleanroom equipment, printed circuit board assembly, and inspection systems, where accuracy and cleanliness are paramount.

General industrial automation applications leverage the VCB22 series for directional control in machine loading and unloading, conveyor systems, lifts, and rotary tables, enhancing operational efficiency and process reliability.

Additionally, the valves are designed to meet NAMUR standards, allowing direct mounting on pneumatic actuators such as cylinders and control valves, which simplifies installation and maintenance.

Finally, the VCB22 series supports manifold systems through multi-valve centralized installations using sub-bases, facilitating integrated piping solutions for complex automation setups.
