Airtac 4V210-08 Directional Control Solenoid Valve Assembly 7 To 10 Station Combined Valve Pack Short Flow Path Low Air Leakage For Multi Channel Air Control System

Product Description:

The 4V series comprises a versatile collection of pilot-operated 5/2-way pneumatic solenoid valves, along with individual replacement coils and pre-assembled multi-station manifold kits. These components are specifically designed to ensure dependable directional control of compressed air within industrial automation systems. The series includes valve port sizes ranging from M5 and 1/8″ up to 1/2″, featuring effective cross-sectional areas that range between 12 mm² and 50 mm². Additionally, the flow coefficients (Cv) vary from 0.56 to 2.80, allowing the valves to suit various actuator dimensions and speed demands.

Valves are offered in multiple configurations: complete single or double solenoid units, valve bodies alone for integration into manifolds or as replacements, and separate AC220V or DC24V replacement coils to facilitate field maintenance. The multi-station manifold kits come pre-arranged with 2 to 10 stations compatible with the 4V210-08 and 4V110-06 models. Dedicated kits are also available for the 4V310-08 and 4V310-10 series. Thanks to the integrated manifold design, several valves are consolidated onto a single robust base, which streamlines installation and conserves space within compact control cabinets. Furthermore, centralized supply and exhaust ports minimize the need for external fittings and reduce potential leak points compared to individual valve piping. Independent wiring for each station also enables mixing AC and DC voltages on one manifold block, enhancing flexibility for systems combining PLC controls with manual safety stations.

The valve bodies are manufactured from aluminum alloy and incorporate a sliding column structure that delivers excellent sealing and a responsive operation. The internal bore undergoes precise machining to minimize friction, which results in a low starting pressure and an extended service life. These valves do not require oil lubrication; however, if lubricated air is used, it must be continuously supplied using ISO VG32 or an equivalent lubricant. A manual override feature is included as standard, allowing installation and troubleshooting without electrical power. The coils have an IP65 rating with power consumption roughly at 3 VA for AC versions or 3 W for DC variants.

Operating specifications include a standard pressure range from 0.15 to 0.8 MPa (21 to 114 psi) and a proof pressure rating of 1.2 MPa (175 psi). These valves are suitable for environments with temperatures spanning from -20°C up to +70°C, making them adaptable to a wide range of industrial applications.

Features:

The port sizes available range from M5 and 1/8 inch up to 1/2 inch. This range accommodates various models including 4V110-M5, 4V110-06, 4V210-06, 4V210-08, 4V310-08, 4V310-10, and 4V410-15, offering flexibility to suit different application needs.

These valves are designed with a 5/2-way pilot-operated directional control mechanism, ensuring reliable switching performance specifically for double-acting cylinders and pneumatic actuators. This feature enhances operational precision and efficiency.

Customers can choose between single and double solenoid options. The double solenoid models incorporate a memory function that holds the valve position, enhancing control reliability during operation.

For system integration or replacement purposes, a valve body only option is available. This is ideal when coils and wiring are already installed, allowing seamless manifold integration without the need for additional components.

Individual replacement coils are offered in both AC220V and DC24V variants. These allow for easy field servicing by enabling coil replacement without the necessity of changing the entire valve assembly, thereby reducing downtime and maintenance costs.

Multi-station manifold kits come pre-assembled in configurations ranging from 2 to 10 stations for models such as 4V210-08 and 4V110-06. Additional kits are available for 4V310-08 and 4V310-10, all designed to minimize installation space and assembly time.

The integrated manifold base consolidates multiple valves onto a single, robust base featuring centralized supply and exhaust ports. This design simplifies system setup and improves overall durability.

A notable feature is the ability to blend voltages on a single manifold. Each station can be wired independently, allowing for the combination of AC and DC voltages within a compact manifold block, enhancing versatility.

Constructed from aluminum alloy, the valve bodies are both lightweight and durable, making them well-suited for demanding industrial environments. This material choice helps to reduce the overall system weight while maintaining strength.

The sliding column structure ensures excellent sealing and a sensitive response with low friction. This results in smooth operation and improved longevity of the valve components.

The valves operate without the need for lubrication, which simplifies maintenance and eliminates the risk of oil-mist contamination—an important consideration in food processing and electronic assembly applications.

A manual override is included as a standard feature, allowing easy installation, troubleshooting, and emergency operation when needed.

Coils are protected to IP65 standards, making them dust-tight and resistant to water jets, which suits the valves for use in challenging environmental conditions.

These valves operate efficiently within a pressure range of 0.15 to 0.8 MPa, suitable for a wide array of industrial pneumatic systems, while the proof pressure is rated at 1.2 MPa to provide a safe margin for pressure surges.

They are designed to perform reliably across a broad temperature range from -20°C to +70°C, accommodating standard industrial ambient conditions.

Technical Parameters:

Applications:

The 5/2-way function is utilized for the extend and retract operations of pneumatic actuators, providing precise double-acting cylinder control. This setup ensures reliable and efficient operation suitable for various industrial applications.

Multi-cylinder automation panels equipped with manifold kits centralize the air supply and wiring. This design supports compact control cabinets that can accommodate up to 10 valve stations, streamlining system integration and maintenance.

A single manifold is capable of hosting both DC 24V PLC-driven valve stations and AC 220V manual safety stations. This flexibility simplifies installation and allows for versatile control system configurations.

Directional control plays a crucial role in manufacturing, assembly, and packaging machinery. These control solutions enable efficient automation processes across various industrial sectors.

Control systems are essential for managing grippers, clamps, and positioning actuators in material handling operations, ensuring accurate and reliable movement of components and products.

The lube-free operation mode prevents oil contamination on production lines, making these control systems ideal for sensitive environments such as food processing and electronics assembly.

Maintenance is simplified with options that allow for replacement of coils and valve bodies individually. This targeted repair approach avoids the need to replace the entire manifold assembly, reducing downtime and costs.

Customization:

Our AirTac 4V210-08 pneumatic valve offers excellent customization services to meet your specific requirements. As a high-quality NAMUR solenoid valve manufactured in China, it comes with CE certification ensuring reliable performance and safety.

The 5/2-way pilot-operated directional control valve features a durable aluminum alloy body and standard NBR seal material, designed for use with air filtered to 40 μm. The valve provides a fast response time of ≤0.03 seconds, making it ideal for precision pneumatic control systems.

We offer customization options including packaging in cartons and flexible payment terms such as T/T, Western Union, and Paypal. With a minimum order quantity of just 1 piece and a supply ability of 5000 pieces per month, we can accommodate both small and large orders efficiently.

Delivery time is swift, ranging from 1 to 7 work days after payment, ensuring your G1/4 pneumatic solenoid valve arrives promptly. Price is negotiable based on order volume and specific customization needs, allowing you to get the best value for your investment.

Choose our product customization services for the AirTac 4V210-08 pneumatic valve to benefit from tailored solutions that enhance your pneumatic system's performance and reliability.
