Product Details:
|
| Brand: | SMC | Connection Type: | Threaded |
|---|---|---|---|
| Tubing 0.D.: | Ø3.2, Ø4, Ø6, Ø8, Ø10, Ø12, Ø16 | Operating Pressure Range: | -100 KPa To 1 MPa |
| Proof Pressure: | 3.0 MPa | Application: | Aerospace Industry |
| Temperature Range: | - 5 To 150°C | Material: | SS316 |
| High Light: | 3.0 MPa Pneumatic Hose Fittings,3.0 MPa Pneumatic Hose Connector,SS316 Pneumatic Hose Connector |
||
The SMC KQG2 series of stainless steel one-touch pneumatic fittings offer engineers reliable performance and excellent protection from chemicals, high temperatures and corrosion. With a compact design, these fittings are 30% smaller and 62% lighter than traditional fittings, allowing the use of tubing diameters ranging from 3.2mm to 16mm.
The KQG2 series is highly versatile, capable of being used with multiple systems such as compressed air, water, and steam. It is constructed with an operating pressure range of (-100kPa to 1MPa) and temperature conditions (-5°C to +150°C). Furthermore, these fittings are made from SUS316 stainless steel, a higher grade than SUS304 stainless steel, improving its pitting and corrosion resistance in chloride environments.
This product is highly compact and light, with approx. 30% shorter dimensions and approx. 62% lighter weight when compared with the KQGL06-01S. It is made of stainless steel 316 for its metal parts as well as special FKM for its seal parts. It can be used with a wide variety of tubing materials, such as FEP, PFA, nylon, soft nylon, polyurethane and polyolefin, at temperatures ranging from -5 to 150°c. Moreover, it is grease-free, making it suitable for use with steam as well.
| Applicable Tubing | Applicable Tubing | FEP, PFA, Nylon, Soft nylon Note 1), Polyurethane, Polyolefin |
| Tubing 0.D. | Ø3.2, Ø4, Ø6, Ø8, Ø10, Ø12, Ø16 | |
| Specifications | Fluid Note 3) |
Air, Water, Steam Note 2) |
| Operating pressure range | -100 kPa to 1 MPa Note 4) | |
| Proof pressure | 3.0 MPa | |
| Ambient and fluid temperature Note 5) | - 5 to 150°C (No freezing) Note 4) | |
| Lubricant | Grease-free specification | |
| Seal on the threads | With sealant | |
| Temperature Condition of Mounting the Inner Sleeve |
Tubing | Temperature |
| FEP tubing/TH Series | 80°C or more | |
| Super PFA tubing/TL Series | 120°C or more | |
Note 1) For soft nylon tubing, water cannot be used.
Note 2) Consult with SMC regarding applicable tube separately.
Note 3) Avoid using in a vacuum holding application such as a leak tester, since there is leakage.
Note 4) Check the operating pressure range and operating temperature range of the tubing.
Note 5) It is recommended that you use the inner sleeve in the following conditions (Except Ø3.2):
●When using at a high temperature.
●When using at a high temperature.
The KQG2 series one-touch fittings are an excellent choice for those who require an easily-used and low-priced solution. These fittings are incredibly adaptable and acceptable for a large variety of tubing materials such as FEP, PFA, nylon, soft nylon, polyurethane, and polyolefin. Not only that, these fittings can also be employed with air, water, and steam, and have FKM seals to top off the protection.
What's more, their oil-free configuration permits straightforward installation and is the perfect choice for steam applications. Consequently, the KQG2 series one-touch fittings are an invaluable asset for anyone who is in need of a qualified and dependable solution.
Pneumatic Hose Fittings offer technical support and service to ensure customer satisfaction. Our team of technical experts is available to answer any questions you may have about installation, maintenance, and troubleshooting. We also provide on-site installation and repair services for any of your pneumatic fittings. Our team is here to provide you with the best possible service experience and ensure your fittings are working properly and safely.
The Pneumatic Hose Fittings are packaged and shipped in the following manner:
- The parts are securely placed in a corrugated cardboard box.
- A packing slip is included in the box and contains the customer’s name, address, and order details.
- The box is then labeled with the customer’s address and the contents.
- The box is then shipped via a reputable carrier to ensure the parts are delivered in a timely manner.
