Name: 2623079 Compact Design Air Solenoid Actuated Valve 5 / 2 Way
Brand: YW DKE TRADING COMPANY
SKU: 2623079
Availability: InStock

Home Products Norgren Solenoid Valve

2623079 Compact Design Air Solenoid Actuated Valve 5 / 2 Way

Product Details:

Place of Origin:	China
Brand Name:	Norgren
Certification:	CE
Model Number:	2623079

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Delivery Time:	1-7Work Days After Payment
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	5000 pieces/1Month

Contact Now

Detailed Product Description

Function:	APB	Medium:	Compressed Air
Operating Temperature:	-10-50℃	Operating Pressure:	2-10 Par
Voltage:	24Vdc	Solenoid Power:	1.2 Watt/VAC
Highlight:	Air Solenoid Actuated valve , Compact Design Solenoid Actuated valve , 2623079 Solenoid Actuated valve

Genuine Norgren 2623079 Compact Design Air Solenoid Actuated Valve

26230,80107 NAMUR&INLINE,3/2&5/2 indirectly electromagnetically actuated piston spool valves

<Port:G1/4, NAMUR interface

<For single and double-acting actuators

<Manual override with detent standard

<Proven design of the piston valve soft seal system

<Variable valve/solenoid combination

<Service-friendly and maintenance-free

Technical features

Medium:	Filtered,lubricated or non-lubricated
	Air
	Compressed air
Actuation:	3/2,5/2and5/3-way
	piston slide valves indirectly operated
	electromagnetically
Operating pressure:	2-8 bar (29--116 psi)
Operating pressure:	1-10 bar (14,5-145psi)
Orifice:	6mm(G1/4),12mm(G1/2)
Port size:	G1/4 NAMUR,G1/4,G1/2
Installation position:	Any,preferably magent vretical
Flow direction:	Fixed
Fuid/Ambient temperature:	-10-+50℃(14-122°F)
	(see solenoid table)
	To prevent the parts from freezing, the compressed air must be below+2℃(+35°F) free of moisture and lubricant!
Materials:	Housing:Aluminium
	Pilot flange:plastic
	Seal:NBR
Additional models:	Upon request
Flow conversion:	Cv US gallon/min(water)=l/min(air)*0.001
Flow conversion:	Kv m³/h(water)=l/min(air)*0.000906
