Product Description:
Material Properties
Main Materials: Typically made of high-quality elastomers (e.g., natural rubber, synthetic rubber like EPDM, NBR, or silicone), often combined with reinforcing fabrics (e.g., nylon or polyester) for enhanced durability.
Chemical Resistance: Resistant to common industrial gases, dust, and moderate chemical exposure, depending on the specific material grade.
Temperature Tolerance: Capable of operating within a wide temperature range (e.g., -20°C to 80°C for standard types; higher-temperature variants may withstand up to 150°C or more).
Mechanical Properties
Flexibility & Elasticity: Exhibits excellent resilience to repeated flexing, ensuring long service life under cyclic pneumatic actuation.
Tensile Strength: High tensile and tear resistance to withstand pressure fluctuations in pulse jet cleaning systems.
Sealing Performance: Precise geometry and material elasticity ensure airtight sealing when the valve is closed, minimizing leakage.
Structural Properties
Thickness: Customizable thickness (e.g., 1-3 mm) to balance flexibility and pressure resistance for different valve models.
Shape & Design: Matched to the specific pulse valve’s structure, often featuring a domed or flat profile with reinforced edges for secure clamping.
Precision Machining: Uniform surface finish and dimensional accuracy to ensure consistent performance across batches.
Operational Properties
Response Speed: Rapid opening and closing under pneumatic pressure, enabling short pulse durations (millisecond-level response).
Cycle Life: Capable of withstanding millions of actuation cycles without significant degradation, depending on operating conditions.
Compatibility: Designed to fit Autel’s range of pulse valves, ensuring interchangeability and easy maintenance.
Environmental Properties
Abrasion Resistance: Resistant to wear from particulate matter in dusty environments (common in industrial filtration systems).
Weatherability: Stable performance in humid, dry, or moderately corrosive atmospheres, suitable for indoor and outdoor applications.
These properties collectively enable Autel pulse valve diaphragms to deliver reliable performance in industrial dust collection, pneumatic conveying, and other pulse jet cleaning systems.
Technical Parameters:
| Screws |
304 Stainless Steel |
| Medium |
Air |
| Color |
White |
| Material |
Nitrile |
| Working Pressure |
0.4~0.8 MPa |
| Working Temperature |
-10~80℃ |
Applications:
The Autel Pulse Valve Diaphragm, also known as the Shockwave Diaphragm Kit, is a high-quality product originating from China. It is designed for various applications across different industries due to its reliability and durability. The product is CE certified, ensuring its compliance with quality and safety standards.
This diaphragm repair accessory is suitable for a wide range of scenarios where pulse valves are used. Its versatile nature allows it to be utilized in dust collectors, air filtration systems, and other pneumatic applications. The Autel Pulse Valve Diaphragm is essential for maintaining the efficiency and performance of pulse valves in these systems.
With a minimum order quantity of 1 and negotiable pricing, customers have the flexibility to procure the product according to their specific requirements. The packaging details include a sturdy carton to ensure safe transportation and delivery.
The delivery time for the Autel Pulse Valve Diaphragm is quick, with orders typically shipped within 1-7 work days after payment confirmation. Customers can choose from various payment terms such as T/T, Western Union, and Paypal, enhancing convenience and accessibility.
With a supply ability of 5000 pieces per month, the Autel Pulse Valve Diaphragm ensures consistent availability for high-demand applications. The product is designed to withstand a working temperature range of -10 to 80℃, making it suitable for diverse environmental conditions.
In addition, the Autel Pulse Valve Diaphragm features a clean white color and is constructed with 304 stainless steel screws for added strength and corrosion resistance. Its working pressure range of 0.4 to 0.8 MPa ensures optimal performance in air-based systems.
Overall, the Autel Pulse Valve Diaphragm is a reliable and efficient product that caters to the needs of various industries requiring high-performance diaphragm repair accessories. Its quality construction and versatile applications make it a valuable component in pulse valve systems.
Packing and Shipping:
Product Name: Pulse Valve Diaphragm
Description: High-quality diaphragm for pulse valves, designed for efficient and reliable performance.
Package Includes: 1 Pulse Valve Diaphragm
Shipping Method: Standard Shipping
Shipping Time: 3-5 business days
Shipping Cost: $5.00
