Place of Origin: | China |
Brand Name: | Autel |
Certification: | CE |
Model Number: | M/D75 |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiation |
Packaging Details: | Carton |
Delivery Time: | 1-7Work Days After Payment |
Payment Terms: | T/T, Western Union,Paypal |
Supply Ability: | 5000 pieces/1Month |
Working Temperature: | -10~80℃ | Screws: | 304 Stainless Steel |
---|---|---|---|
Material: | Nitrile | Color: | White |
Working Pressure: | 0.4~0.8 MPa | Medium: | Air |
Main Materials: Autel pulse valve diaphragms are typically made of high-quality elastomers such as natural rubber, synthetic rubber like EPDM, NBR, or silicone. These materials are often combined with reinforcing fabrics like nylon or polyester to enhance durability.
Chemical Resistance: Autel pulse valve diaphragms are resistant to common industrial gases, dust, and moderate chemical exposure, depending on the specific material grade.
Temperature Tolerance: These diaphragms are capable of operating within a wide temperature range, for example, -20°C to 80°C for standard types. Higher-temperature variants may withstand up to 150°C or more.
Flexibility & Elasticity: Autel diaphragms exhibit excellent resilience to repeated flexing, ensuring long service life under cyclic pneumatic actuation.
Tensile Strength: They also have high tensile and tear resistance to withstand pressure fluctuations in pulse jet cleaning systems.
Sealing Performance: The precise geometry and material elasticity of Autel diaphragms ensure airtight sealing when the valve is closed, minimizing leakage.
Thickness: Autel pulse valve diaphragms come in customizable thicknesses, such as 1-3 mm, to balance flexibility and pressure resistance for different valve models.
Shape & Design: The shape and design of the diaphragms are matched to specific pulse valve structures, often featuring a domed or flat profile with reinforced edges for secure clamping.
Precision Machining: These diaphragms have uniform surface finish and dimensional accuracy to ensure consistent performance across batches.
Response Speed: Autel diaphragms offer rapid opening and closing under pneumatic pressure, enabling short pulse durations at the millisecond level response.
Cycle Life: They are capable of withstanding millions of actuation cycles without significant degradation, depending on operating conditions.
Compatibility: Autel diaphragms are specifically designed to fit Autel’s range of pulse valves, ensuring interchangeability and easy maintenance.
Abrasion Resistance: These diaphragms are resistant to wear from particulate matter in dusty environments, which is common in industrial filtration systems.
Weatherability: Autel diaphragms offer stable performance in humid, dry, or moderately corrosive atmospheres, making them suitable for indoor and outdoor applications.
These properties collectively enable Autel pulse valve diaphragms to deliver reliable performance in industrial dust collection, pneumatic conveying, and other pulse jet cleaning systems.
Screws | 304 Stainless Steel |
Color | White |
Working Pressure | 0.4~0.8 MPa |
Medium | Air |
Working Temperature | -10~80℃ |
Material | Nitrile |
Diaphragm
Order Code
|
Diaphragm Reference No
|
Pulse Valve
Model No
|
Pulse Valve
Port Size
|
Diaphragm
Material
|
AE18
|
M/D20
|
AE1818B, AE2818B
AE1822B, AE2822B
|
3/4'', 1''
|
TPE (Standard)
FKM+PTFE (High Temperature)
|
AE25
|
M/D25
|
AE1825B, AE2825B
AE1825R, AE2825R
|
1''
|
|
AE40
|
M/D40
|
AE1440B, AE2440B
AE1440R, AE2440R
|
1-1/2''
|
|
AE50
|
M/D50
M/D60
|
AE1450B, AE2450B
AE1460B, AE2460B
|
2'', 2-1/2''
|
|
AE75
|
M/D75
|
AE1475I12, AE2475I12
|
3''
|
The Autel Pulse Valve Diaphragm is a high-quality product originating from China, designed for various applications in industrial settings. With its CE certification, this diaphragm ensures reliability and performance in diverse working conditions.
Product Application Occasions and Scenarios:
- **Industrial Manufacturing**: The Autel Pulse Valve Diaphragm is ideal for use in industrial manufacturing plants where air control is essential. Its durable Nitrile material and 304 Stainless Steel screws make it suitable for demanding environments.
- **Dust Collection Systems**: This diaphragm is a crucial component in dust collection systems, helping to regulate air flow and maintain efficiency. Its working pressure range of 0.4~0.8 MPa ensures optimal performance in such applications.
- **HVAC Systems**: The Autel Pulse Valve Diaphragm can also be used in HVAC systems to control air flow and pressure. Its wide working temperature range of -10~80℃ makes it versatile for different climate conditions.
- **Pneumatic Conveying Systems**: In industries utilizing pneumatic conveying systems, this diaphragm serves as a reliable medium for air control. Its Shockwave Diaphragm Kit ensures easy repair and maintenance, reducing downtime.
- **Automated Production Lines**: The diaphragm is suitable for use in automated production lines where precise air control is essential for efficient operations. Its compatibility with various payment methods and quick delivery time of 1-7 workdays make it convenient for procurement.
With a minimum order quantity of 1 and negotiable pricing, the Autel Pulse Valve Diaphragm offers flexibility for both small-scale and large-scale users. Packaged in cartons for secure transportation, this product has a supply ability of 5000 pieces per month, ensuring consistent availability for customers.
Product: Pulse Valve Diaphragm
Description: High-quality replacement diaphragm for pulse valves.
Packaging: Each diaphragm is individually wrapped in protective packaging to prevent damage during shipping.
Shipping: We carefully pack and ship your order to ensure safe delivery to your doorstep.
