| Type |
[Fitting] One-Touch Coupling |
Fitting Type |
Union with different diameters |
| Tube Size 1(φ) |
10 |
Tube Size 2(φ) |
12 |
| Body Material |
316 Stainless Steel |
Application |
Standard |
| Thread Portion Material |
No Thread Part |
Seal/O-Ring Material |
[Fluororubber] Special FKM (Fluorine Coated) |
| Tube to Tube Reducing Union Shape |
[Unequal Dia. Union Straight] Unequal Diameter Straight |
Compatible Fluid |
Water / Air |
| Type Of Connection |
Tube Connection |
Number of Connection Tubes(piece) |
2 |
Product Description:
The joint is crafted from stainless steel 304 material, and it is designed for application in environments free of copper and zinc as well as corrosive settings.
There are numerous models and specifications available, making it a popular choice in a variety of pneumatic systems.
Offering outstanding flow performance, the joint features simple and convenient plug-and-play connections, ensuring secure, reliable, and long-lasting connections with the airway.
To prevent leakage in the threaded connection section, the threaded part is coated with sealant, and M5 metric threads come equipped with sealing rings.
Applications:
Industrial Dust Removal and Environmental Protection Equipment
Bag type dust removal system: connecting pulse valve and air bag, used for high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as DMF-Y submerged valve matching).
Sewage treatment aeration control: corrosion-resistant design to resist acidic media, suitable for quick connection of pneumatic pipelines.
Food and Pharmaceutical Industry
Aseptic fluid delivery: Oil free design+FKM seal, compliant with FDA standards, used for steam cleaning pipelines in filling lines (such as KQG2H16-04S type).
High temperature disinfection system: resistant to steam at 150 ℃, suitable for fermentation tanks and CIP cleaning pipelines.
Chemical and Energy Fields
Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and solvents and is used for chemical agent transportation pipelines.
Steam power system: The straight through structure (such as KQG2H23-00) optimizes the connection of steam pipelines to reduce the risk of leakage.
Automation and Pneumatic Control
Pneumatic actuator connection: Compact design integrated into the robotic arm fixture (such as CQ2 cylinder pipeline) to improve response speed.
Vacuum equipment: supports -100kPa vacuum environment, used for suction cup control system in electronic semiconductor manufacturing.
Support and Services:
Product Technical Support and Services for Pneumatic Pipe Fittings:
- Troubleshooting assistance for installation and operation issues
- Product maintenance and repair services
- Technical documentation and manuals for reference
- Training and educational resources for proper usage
Packing and Shipping:
Product Packaging and Shipping:
Our high-quality Pneumatic Pipe Fittings are carefully packaged to ensure they reach you in perfect condition. Each fitting is individually wrapped in protective material to prevent any damage during transit.
For shipping, we use trusted carriers to deliver your order safely and efficiently. You can track your package using the provided tracking number to know exactly when it will arrive.
