| Type |
[Fitting] One-Touch Coupling |
Fitting Type |
Union with different diameters |
| Tube Size 1(φ) |
4 |
Tube Size 2(φ) |
6 |
| Body Material |
316 Stainless Steel |
Application |
Standard |
| Thread Portion Material |
No Thread Part |
Seal/O-Ring Material |
[Fluororubber] Special FKM (Fluorine Coated) |
| Tube to Tube Reducing Union Shape |
[Unequal Dia. Union Straight] Unequal Diameter Straight |
Compatible Fluid |
Water / Air |
| Type Of Connection |
Tube Connection |
Number of Connection Tubes(piece) |
2 |
Product Description:
SMC’s KQG2 stainless steel range provides engineers with a choice of high performance, lightweight, compact push in fittings for when resistance to corrosion, chemicals and high temperatures is vital. 30% smaller and 62% lighter than the existing KQG range and available to tubing diameters from 3.2 to 16mm. Suitable for use with compressed air, water, steam and able to perform across a diverse range of pressure (-100kPa to 1MPa) and temperature conditions (-5°C to +150°C).
Threaded, Tube-to-Tube & Adaptors - SMC KQG2
Applications:
Industrial dust removal and environmental protection equipment
Bag type dust removal system: connecting pulse valve and air bag, used for high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as DMF-Y submerged valve matching).
Sewage treatment aeration control: corrosion-resistant design to resist acidic media, suitable for quick connection of pneumatic pipelines.
Food and pharmaceutical industry
Aseptic fluid delivery: Oil free design+FKM seal, compliant with FDA standards, used for steam cleaning pipelines in filling lines (such as KQG2H16-04S type).
High temperature disinfection system: resistant to steam at 150 ℃, suitable for fermentation tanks and CIP cleaning pipelines.
Chemical and energy fields
Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and solvents and is used for chemical agent transportation pipelines.
Steam power system: The straight through structure (such as KQG2H23-00) optimizes the connection of steam pipelines to reduce the risk of leakage.
Automation and Pneumatic Control
Pneumatic actuator connection: Compact design integrated into the robotic arm fixture (such as CQ2 cylinder pipeline) to improve response speed.
Vacuum equipment: supports -100kPa vacuum environment, used for suction cup control system in electronic semiconductor manufacturing.
Support and Services:
Our Pneumatic Pipe Fittings product includes comprehensive technical support and services to ensure optimal performance and customer satisfaction. Our team of experts is available to assist with installation guidance, troubleshooting, and maintenance tips. Additionally, we offer training programs and resources to help customers maximize the benefits of our pneumatic pipe fittings. Feel free to reach out to our support team for any assistance you may need.
Packing and Shipping:
Product Packaging:
The pneumatic pipe fittings are carefully packed in a sturdy cardboard box to ensure safe delivery. Each fitting is individually wrapped in protective material to prevent any damage during transit.
Shipping:
Orders for pneumatic pipe fittings are usually shipped within 1-2 business days. We offer standard and expedited shipping options to meet your delivery needs. Once your order is dispatched, you will receive a tracking number to monitor the status of your shipment.
