KQG2L08-02S SMC Stainless Steel Bent L-shaped Joint ,90° Elbow,8 Mm X R1/4, KQG2 Series

Product Description:

Core Features and Design Advantages

Material and Sealing

SUS316 stainless steel: significantly superior to 304 stainless steel in terms of pitting and chloride corrosion resistance, suitable for high corrosion environments such as chemical and marine industries.

FKM seal: resistant to temperatures up to 150 ℃, compatible with steam and chemical solvents, and does not require lubricating grease, meeting the hygiene requirements of the food/pharmaceutical industry.

Lightweight and Compact Structure

The volume of the KQG series is reduced by 30% compared to the old model, and the weight is reduced by 62%. It is suitable for pipes with a diameter of 3.2~16mm and is suitable for devices with limited space.

Wide Working Condition Adaptability

Pressure range: -100kPa (vacuum) to 1MPa (pressure resistance 3MPa).

Temperature range: -5 ℃~+150 ℃, supporting steam medium.

Applications:

Food and pharmaceutical industry

Aseptic fluid delivery: Oil free design+FKM sealing meets FDA standards, used for filling lines, CIP (in-situ cleaning) steam pipelines (such as model KQG2L16-04S connected to steam disinfection systems).

High temperature disinfection: Resistant to steam at 150 ℃, applied to fermentation tanks and sterilization equipment pipelines.

Chemical and energy equipment

Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and organic solvents, and is used for chemical agent transportation pipelines (such as sulfuric acid and chlor alkali processes).

Steam power system: The straight through structure (such as KQG2L12-00) optimizes the connection of steam pipelines to reduce the risk of leakage.

Industrial environmental protection equipment

Dust removal system: Connect pulse valve and air bag, used for high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as matching DMF-Y submerged valve).

Wastewater treatment aeration: acid resistant medium design, suitable for quick connection of pneumatic pipelines (such as aeration tank control valves).

Automated pneumatic control

Precision equipment integration: Compact structure (such as KQG2L23-M5) is suitable for mechanical arm fixtures, sensor air path connections, and improves space utilization.

Vacuum system: supports -100kPa vacuum environment, used for suction cup control in semiconductor manufacturing.
