Product Description:
Core Features and Design Advantages
Material and sealing
SUS316 stainless steel: significantly superior to 304 stainless steel in terms of pitting and chloride corrosion resistance, suitable for high corrosion environments such as chemical and marine industries.
FKM seal: resistant to temperatures up to 150 ℃, compatible with steam and chemical solvents, and does not require lubricating grease, meeting the hygiene requirements of the food/pharmaceutical industry.
Lightweight and compact structure
The volume of the KQG series is reduced by 30% compared to the old model, and the weight is reduced by 62%. It is suitable for pipes with a diameter of 3.2~16mm and is suitable for devices with limited space.
Wide working condition adaptability
Pressure range: -100kPa (vacuum) to 1MPa (pressure resistance 3MPa).
Temperature range: -5 ℃~+150 ℃, supporting steam medium.
Applications:
Food and pharmaceutical industry
Aseptic fluid delivery: Oil free design+FKM sealing meets FDA standards, used for filling lines, CIP (in-situ cleaning) steam pipelines (such as model KQG2L16-04S connected to steam disinfection systems).
High temperature disinfection: Resistant to steam at 150 ℃, applied to fermentation tanks and sterilization equipment pipelines.
Chemical and energy equipment
Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and organic solvents, and is used for chemical agent transportation pipelines (such as sulfuric acid and chlor alkali processes).
Steam power system: The straight through structure (such as KQG2L12-00) optimizes the connection of steam pipelines to reduce the risk of leakage.
Industrial environmental protection equipment
Dust removal system: Connect pulse valve and air bag, used for high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as matching DMF-Y submerged valve).
Wastewater treatment aeration: acid resistant medium design, suitable for quick connection of pneumatic pipelines (such as aeration tank control valves).
Automated pneumatic control
Precision equipment integration: Compact structure (such as KQG2L23-M5) is suitable for mechanical arm fixtures, sensor air path connections, and improves space utilization.
Vacuum system: supports -100kPa vacuum environment, used for suction cup control in semiconductor manufacturing.
| Brand: |
SMC |
| Fitting/Connector Type: |
Elbow |
| Hex Size: |
12 mm |
| Length: |
18.6 mm |
| Manufacturer: |
SMC Corporation of America |
| Material: |
Stainless Steel |
| Name: |
SMC KQG2L08-01S KQG2 Pneumatic Elbow, 8 mm x R1/8 Nominal, Stainless Steel |
| Nominal Size: |
8 mm x R1/8 |
| Pressure Rating: |
-100 KPa to 1 MPa |
| Product Type: |
Simple |
| Series: |
KQG2 |
| Temperature Rating: |
-5 to 150 deg C |
| Unit Of Measure: |
EA |
| Weight: |
1.00 |
Support and Services:
Our Pneumatic Pipe Fittings product comes with comprehensive technical support and services to ensure smooth operation and customer satisfaction. Our team of experts is available to assist with any product-related inquiries, troubleshooting, or installation guidance. We also provide maintenance services to keep your pneumatic systems running efficiently. Contact us for more information on our technical support offerings.
Packing and Shipping:
Product Packaging:
Our Pneumatic Pipe Fittings are carefully packaged to ensure their protection during transit. Each fitting is individually wrapped in bubble wrap to prevent any damage. The fittings are then placed in a sturdy cardboard box with ample cushioning material to further safeguard them from any potential impacts.
Shipping Information:
Once your order is confirmed, our team will process it swiftly to ensure timely delivery. We partner with trusted shipping carriers to deliver your Pneumatic Pipe Fittings safely to your doorstep. You will receive a tracking number to monitor the shipment progress and expected delivery date.
