| Type |
[Fitting] One-Touch / Screw |
Fitting Type |
Screw Mount Direction |
| Tube Size 1(φ) |
6 |
Threaded Adapter Shape |
[Elbows] Elbow |
| Body Material |
316 Stainless Steel |
Application |
Standard |
| Thread Portion Material |
316 Stainless Steel |
Seal/O-Ring Material |
[Fluororubber] Special FKM (Fluorine Coated) |
| Threaded Adapter Elbow Shape |
[Male Elbows] Male Elbow |
Compatible Fluid |
Water / Air |
| Type Of Connection |
BSPT |
Connection Screw |
3/8" |
Product Description:
Push to Connect Fittings (KQG2L06-03S)
90° Elbow, Thread Sealant, Male NPT/UNF/BSPT/Metric Thread to Metric/Inch Tube, SS316, KQG2 Series
SMC One-Touch fitting.
Features
· Compact and lightweight.
· Grease-free.
· Can be used with steam.
· Metal part: SUS316, Seal part: special FKM.
· Working fluid temperature: -5 to +150°C
· Conforms to the Food Sanitation Act of Japan. (Part materials conform to the tool and packaging container standards test.)
Applications
· Used for perpendicular piping from a female thread.
Applications:
Food and Pharmaceutical Industry
Aseptic fluid delivery: Oil-free design+FPM sealing meets FDA standards, utilized for filling lines, CIP (in-situ cleaning) steam pipelines (such as model KQG2L16-04S connected to steam disinfection systems).
High-temperature disinfection: Resistant to steam at 150°C, applied to fermentation tanks and sterilization equipment pipelines.
Chemical and Energy Equipment
Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and organic solvents, and is used for chemical agent transportation pipelines (such as sulfuric acid and chlor alkali processes).
Steam power system: The straight-through structure (such as KQG2L12-00 ) optimizes the connection of steam pipelines to reduce the risk of leakage.
Industrial Environmental Protection Equipment
Dust removal system: Connect pulse valve and airbag, used for the high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as matching DMF-Y submerged valve).
Wastewater treatment aeration: Acid-resistant medium design, suitable for quick connection of pneumatic pipelines (such as aeration tank control valves).
Automated Pneumatic Control
Precision equipment integration: Compact structure (such as KQG2L23-M5 ) is suitable for mechanical arm fixtures, sensor air path connections, and improves space utilization.
Vacuum system: Supports -100kPa vacuum environment, used for suction cup control in semiconductor manufacturing.
| Brand: |
SMC |
| Fitting/Connector Type: |
Elbow |
| Hex Size: |
17 mm |
| Length: |
15.9 mm |
| Manufacturer: |
SMC Corporation of America |
| Material: |
Stainless Steel |
| Name: |
SMC KQG2L06-03S KQG2 Pneumatic Elbow, 6 mm x R3/8 Nominal, Stainless Steel |
| Nominal Size: |
6 mm x R3/8 |
| Pressure Rating: |
-100 KPa to 1 MPa |
| Product Type: |
Simple |
| Series: |
KQG2 |
| Temperature Rating: |
-5 to 150 deg C |
| Unit Of Measure: |
EA |
| Weight: |
1.00 |
Support and Services:
Our Product Technical Support and Services for Pneumatic Pipe Fittings include:
- Assistance with product selection and compatibility
- Troubleshooting guidance for installation and operation
- Maintenance tips and recommendations
- Repair services and replacement parts availability
