Product Description:
Series KQG2 is a one touch fitting made of all stainless steel SUS316, except seal parts. The Series is suitable for use with steam and is grease-free. Applicable tubing includes FEP, PFA, nylon, soft nylon, polyurethane and polyolefin. The KQG2 Series is available in both metric and inch sizes. The KQG2 is more compact and lightweight and offers more configuration variations and tube sizes than the KQG Series.
Applications:
Food and Pharmaceutical Industry
Aseptic fluid delivery: Oil free design with FKM sealing that meets FDA standards is utilized for filling lines, CIP (cleaning in place) steam pipelines, such as model KQG2L16-04S connected to steam disinfection systems.
High-temperature disinfection: Able to withstand steam at 150℃, this is applied to fermentation tanks and sterilization equipment pipelines.
Chemical and Energy Equipment
Corrosive medium transmission: Made of SUS316 material, it is resistant to acids, alkalis, and organic solvents, making it suitable for chemical agent transportation pipelines in processes like sulfuric acid and chlor-alkali.
Steam power system: The straight-through structure, like KQG2L12-00 , optimizes the connection of steam pipelines to minimize the risk of leakage.
Industrial Environmental Protection Equipment
Dust removal system: Connected with a pulse valve and airbag, it is used in high-temperature dust environments such as cement plant kiln tails and steel plant sintering machines, with components like the matching DMF-Y submerged valve .
Wastewater treatment aeration: Designed for acid-resistant mediums, it is ideal for the quick connection of pneumatic pipelines, like aeration tank control valves.
Automated Pneumatic Control
Precision equipment integration: The compact structure, such as KQG2L23-M5 , is well-suited for mechanical arm fixtures, sensor air path connections, and enhances space utilization.
Vacuum system: Capable of supporting a -100kPa vacuum environment, it is used for suction cup control in semiconductor manufacturing.
| Brand: |
SMC |
| Dimensions: |
11.4 mm Dia |
| End Style: |
Tube x MNPT |
| Fitting/Connector Type: |
Elbow |
| Hex Size: |
10 |
| Manufacturer: |
SMC Corporation of America |
| Material: |
316 Stainless Steel |
| Name: |
SMC KQG2L06-01S 90 deg Elbow With Sealant, Elbow, 6 mm x R1/8, Tube x MNPT End Style, 316 Stainless Steel |
| Nominal Size: |
6 mm x R1/8 |
| Pressure Rating: |
-100 kPa to 1 MPa |
| Product Type: |
Simple |
| Series: |
KQG2 |
| Temperature Rating: |
-5 to 150 |
| Type: |
90 deg |
| Unit Of Measure: |
EA |
| UNSPSC: |
40172800 |
| Weight: |
1.00 |
Support and Services:
Our Pneumatic Pipe Fittings product comes with comprehensive technical support and services to ensure smooth operation and customer satisfaction. Our team of experts is available to assist with installation guidance, troubleshooting, and maintenance tips. We also offer training programs to help customers better understand the product and optimize its performance. Additionally, our service team provides prompt assistance for any product-related issues or inquiries. Rest assured, we are committed to delivering top-notch support to meet your needs.
Packing and Shipping:
Product Packaging for Pneumatic Pipe Fittings:
Each pneumatic pipe fitting will be securely packaged in individual plastic bags to prevent scratching and damage during transit. The fittings will then be placed in a sturdy cardboard box with ample cushioning material to provide protection during shipping.
Shipping Information:
Orders for pneumatic pipe fittings will be processed within 1-2 business days. We offer standard shipping options as well as expedited shipping for urgent orders. Customers will receive a tracking number once the order has been shipped for easy monitoring of the delivery status.
