Product Description:
Material and Sealing
SUS316 stainless steel: is significantly superior to 304 stainless steel in terms of pitting and chloride corrosion resistance. It is suitable for high-corrosion environments such as chemical and marine industries.
FKM seal: is resistant to temperatures up to 150°C and is compatible with steam and chemical solvents. It does not require lubricating grease, meeting the hygiene requirements of the food/pharmaceutical industry.
Lightweight and Compact Structure
The volume of the KQG series is reduced by 30% compared to the old model, and the weight is reduced by 62%. It is suitable for pipes with a diameter of 3.2~16mm and is suitable for devices with limited space.
Wide Working Condition Adaptability
Pressure range: -100kPa (vacuum) to 1MPa (pressure resistance 3MPa).
Temperature range: -5°C to +150°C, supporting steam medium.
Applications:
Food and Pharmaceutical Industry
Aseptic fluid delivery: Oil free design+FKM sealing meets FDA standards, used for filling lines, CIP (in-situ cleaning) steam pipelines (such as model KQG2L16-04S connected to steam disinfection systems).
High temperature disinfection: Resistant to steam at 150 ℃, applied to fermentation tanks and sterilization equipment pipelines.
Chemical and Energy Equipment
Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and organic solvents, and is used for chemical agent transportation pipelines (such as sulfuric acid and chlor alkali processes).
Steam power system: The straight through structure (such as KQG2L12-00) optimizes the connection of steam pipelines to reduce the risk of leakage.
Industrial Environmental Protection Equipment
Dust removal system: Connect pulse valve and air bag, used for high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as matching DMF-Y submerged valve).
Wastewater treatment aeration: acid resistant medium design, suitable for quick connection of pneumatic pipelines (such as aeration tank control valves).
Automated Pneumatic Control
Precision equipment integration: Compact structure (such as KQG2L23-M5) is suitable for mechanical arm fixtures, sensor air path connections, and improves space utilization.
Vacuum system: supports -100kPa vacuum environment, used for suction cup control in semiconductor manufacturing.
| Brand: |
SMC |
| Dimensions: |
9.1 mm Dia |
| End Style: |
Tube x MNPT |
| Fitting/Connector Type: |
Elbow |
| Hex Size: |
14 |
| Manufacturer: |
SMC Corporation of America |
| Material: |
316 Stainless Steel |
| Name: |
SMC KQG2L04-02S 90 deg Elbow With Sealant, Elbow, 4 mm x R1/4, Tube x MNPT End Style, 316 Stainless Steel |
| Nominal Size: |
4 mm x R1/4 |
| Pressure Rating: |
-100 kPa to 1 MPa |
| Product Type: |
Simple |
| Series: |
KQG2 |
| Temperature Rating: |
-5 to 150 |
| Type: |
90 deg |
| Unit Of Measure: |
EA |
| UNSPSC: |
40172800 |
| Weight: |
1.00 |
Support and Services:
Product Technical Support and Services for Pneumatic Pipe Fittings:
Our team of experienced technicians is available to provide technical support for the installation, maintenance, and troubleshooting of our pneumatic pipe fittings. We offer comprehensive training programs to ensure proper use and functionality of our products.
Additionally, we provide repair and replacement services for any faulty or damaged pneumatic pipe fittings. Our goal is to assist our customers in maximizing the performance and efficiency of their pneumatic systems.
Packing and Shipping:
Product Packaging and Shipping:
Our Pneumatic Pipe Fittings are carefully packaged to ensure they arrive in perfect condition. Each fitting is individually wrapped in protective material and placed in a sturdy cardboard box to prevent any damage during shipping.
For shipping, we use reliable courier services to deliver your order safely and on time. You will receive a tracking number once your order has been dispatched, allowing you to monitor the delivery status.
