Product Description:
Introduction
The SMC KQG2H Series comprises stainless steel 316 (SUS316) one-touch fittings that are specifically engineered to cater to applications necessitating high corrosion resistance, chemical resistance, and high temperature tolerance.
Key Features
These sophisticated fittings embody a push-to-connect design, with metal components crafted from SUS316 stainless steel and seal parts fashioned from special FKM material. Notably, they are devoid of grease and are apt for deployment with steam.
Enhancements
In contrast with the preceding KQG series, the KQG2H Series demonstrates a significant advancement. It is markedly more compact, boasting a reduction in volume by 30% and a decrease in weight by 62%. Furthermore, it is available in both metric and inch sizes, enhancing its versatility and applicability.
Features:
Premium Material: Metal parts made of SUS316 stainless steel, providing better corrosion and pitting resistance than 304 stainless steel, especially in chloride environments.
Compact & Lightweight: 30% smaller volume and 62% weight reduction compared to the traditional KQG series, ideal for space-constrained applications.
High Temperature Resistance: Fluid temperature range from -5°C to +150°C.
Wide Compatibility: Applicable to various tubing materials including FEP, PFA, nylon, soft nylon, polyurethane, polyolefin, etc.
Multi-Fluid Application: Suitable for air, water, steam, and other fluids.
Safe & Reliable: Operating pressure range -100kPa to 1MPa, with a proof pressure of 3.0MPa.
Technical Parameters:
| Applicable Tubing Material |
FEP, PFA, Nylon, Soft Nylon |
| Fluid Temperature |
-5 to 150˚C |
| Metal Parts |
Stainless Steel 316 |
| Fluid |
Air, Water, Steam |
| Proof Pressure |
3.0 MPa |
| Seal Parts |
Special FKM |
Applications:
Food & Pharmaceutical Industry: Complies with Japanese Food Hygiene Law requirements, suitable for food and pharmaceutical equipment.
Semiconductor & Electronics Industry: Ideal for gas and liquid transfer in high-purity environments.
Chemical Processing: Corrosion-resistant characteristics suitable for chemical transfer systems.
High-Temperature Steam Environments: Applicable for equipment requiring steam cleaning or sterilization.
Support and Services:
Our Pneumatic Pipe Fittings come with comprehensive product technical support and services to ensure optimal performance and customer satisfaction. Our team of experts is available to provide assistance with product selection, installation guidance, troubleshooting, and maintenance tips. Additionally, we offer training programs and resources to help customers maximize the efficiency and longevity of their pneumatic systems. Contact us for more information on our technical support and services for Pneumatic Pipe Fittings.
Packing and Shipping:
Product Packaging:
Our pneumatic pipe fittings are carefully packed in sturdy cardboard boxes to ensure safe transportation. Each fitting is individually wrapped in protective material to prevent any damage during shipping.
Shipping Information:
Orders are typically shipped within 1-2 business days. We offer standard and expedited shipping options to meet your needs. Once your order is processed, you will receive a tracking number to monitor the delivery status of your pneumatic pipe fittings.
