AS1201F-M3-03 SMC Pneumatic Control Valve AS Series

AS1201F-M3-03 SMC Pneumatic Control Valve AS Series

  • AS1201F-M3-03 SMC Pneumatic Control Valve AS Series
  • AS1201F-M3-03 SMC Pneumatic Control Valve AS Series
  • AS1201F-M3-03 SMC Pneumatic Control Valve AS Series
  • AS1201F-M3-03 SMC Pneumatic Control Valve AS Series
  • AS1201F-M3-03 SMC Pneumatic Control Valve AS Series
AS1201F-M3-03 SMC Pneumatic Control Valve AS Series
Product Details:
Brand Name: SMC
Certification: CE
Model Number: AS1201F-M3-03
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Negotiation
Packaging Details: Carton /As The Clients Require
Delivery Time: 1-7Work Days After Payment
Payment Terms: T/T,Western Union,Paypal
Supply Ability: 5000 Pieces/1Month
Contact Now
Detailed Product Description
Applicable Tubing Material: Nylon, Soft Nylon, Polyurethane Ambient And Fluid Temperature: –5 To 60°C (No Freezing)
Mini. Operating Pressure: 0.1 MPa Proof Pressure: 1.5 MPa
Fluid: Air Max. Operating Pressure: 1 MPa
Highlight:

SMC pneumatic control valve AS series

,

AS1201F-M3-03 pneumatic valve

,

pneumatic pipe fittings control valve

Product Description:

Enhanced Visibility and Scale: Many models feature a scale window for numerical flow management, with some including a vernier for precise 1/4-scale settings. The scale is visible from 360 degrees, improving accessibility for inspection and maintenance.

Ergonomic and Efficient Operation: The push-to-lock mechanism enhances needle valve locking operation, making setup faster and reducing setup time and potential errors. Some models also have a larger knob diameter (approximately twice as large) for easier adjustment.

Space-Saving and Lightweight Design: The compact design saves space, and some models achieve weight reduction of about 27%.

Easy Installation and Connection: Tube insertion and removal are facilitated with reduced insertion force (by up to 30%) and withdrawal force (by up to 20%) while maintaining pull-out strength. The 360° free orientation piping capability (in elbow/universal types) allows for flexible installation.

Durability and Specialized Specifications: Constructed with metal bodies (e.g., zinc alloy) or specific materials for standard use, with some offering stainless steel for corrosion resistance. Non-electrolytic nickel plating is standardized for some components. Options include cleanroom (low-dust generation) and corrosion-resistant models.

Integrated Functions: Certain variants combine a speed control valve with other functions, such as a residual pressure release valve (for one-button exhaust) or a pilot-operated check valve (for cylinder speed control and temporary intermediate stopping).


Applications:

The AS series speed control valves from SMC are primarily utilized for regulating the speed of pneumatic actuators by controlling the flow of compressed air.

Designed specifically for low-speed control applications, these valves are ideal for achieving cylinder movement speeds ranging from 1 mm/s to 50 mm/s or 50 mm/s to 150 mm/s.

For general speed regulation in pneumatic systems, they are commonly used for meter-out flow control, typically achieved through exhaust port throttling in one direction, while allowing unrestricted flow in the opposite direction thanks to the inclusion of a built-in check valve. This feature facilitates convenient and consistent speed adjustment.

These valves are particularly suitable for applications that demand compact and efficient components. Their compact and lightweight design makes them well-suited for use in machinery and systems where optimal space utilization is crucial.

Moreover, specialized variants of these valves are available for use in specific environments like cleanrooms to minimize dust generation and environments necessitating materials resistant to corrosion.

We hope this translation and summary offer valuable insights into the functionality and versatility of the SMC AS series speed control valves. Should you require more detailed information about a particular model or application, please do not hesitate to reach out.

AS1201F-M3-03 SMC Pneumatic Control Valve AS Series 0

AS1201F-M3-03 SMC Pneumatic Control Valve AS Series 1

AS1201F-M3-03 SMC Pneumatic Control Valve AS Series 2

AS1201F-M3-03 SMC Pneumatic Control Valve AS Series 3

AS1201F-M3-03 SMC Pneumatic Control Valve AS Series 4


Support and Services:

Our Product Technical Support team for Pneumatic Pipe Fittings is dedicated to providing assistance with installation, troubleshooting, and maintenance of our products. Our team of experts is available to answer any technical questions and provide guidance to ensure optimal performance of your pneumatic systems.

In addition to technical support, we also offer a range of services for Pneumatic Pipe Fittings, including customization options, on-site consultations, and training programs. Our goal is to help you maximize the efficiency and reliability of your pneumatic systems through our comprehensive support and services.


Packing and Shipping:

Product Packaging:

Our pneumatic pipe fittings are carefully packaged to ensure they arrive at your doorstep in perfect condition. Each fitting is sealed in a protective plastic wrapping to prevent any damage during transit. The fittings are then placed in a sturdy cardboard box with ample cushioning material to absorb any shocks or impacts during shipping.

Shipping Information:

Once your order is confirmed, our team will process it promptly. We partner with reliable shipping carriers to deliver your pneumatic pipe fittings to you safely and on time. You will receive a tracking number to monitor the status of your shipment. We take great care in packaging your fittings to minimize the risk of damage during transportation.
