Product Description:
Compact Design & Modularity
The valve features an ultra-thin body, measuring just 18 millimeters in width
for the medium size within its series (10/14/18/24 mm). This slim profile
significantly reduces the space required for installation.
Additionally, the valve system is designed with modularity in mind. Multiple
valve modules can be easily assembled on a manifold base through a bayonet
connection, which eliminates the need for screws. This allows the creation
of a compact valve terminal that can accommodate between 2 and 10 valve
stations. The terminal is constructed using high-strength, glass-fiber
reinforced polyamide combined with an aluminum rail, ensuring a durable and
robust framework.
High Performance & Efficiency
This valve is capable of delivering an impressive maximum flow rate of up to
3200 liters per minute. Despite the high flow capacity, it maintains very
low power consumption, typically around 1.5 watts for DC models, resulting in
superior energy efficiency.
Furthermore, the valve offers rapid switching times, generally occurring within
tens of milliseconds. This quick response helps to minimize machine cycle
durations, enhancing overall operational efficiency.
Applications:
The CPE18 series solenoid valve stands out as an excellent choice due to its compact size, high efficiency, and versatility. These qualities make it well-suited for a wide range of applications across various industries.
In the realm of general industrial automation, the CPE18 valve is extensively utilized. It plays a critical role in material handling processes, assembly lines, and packaging machinery, where it helps control cylinders to perform pushing, pulling, clamping, and lifting operations with precision and reliability.
For equipment with limited space, this solenoid valve proves especially advantageous. Its compact design allows for seamless integration into tight workstations, robotic end-effectors, and enclosed areas where space constraints are a significant consideration.
Moreover, the CPE18 series excels in complex pneumatic setups that demand centralized control. Its modular valve terminal configuration enables efficient management of multiple pneumatic circuits within multi-actuator workstations or machining centers, thereby reducing wiring complexity and enhancing system organization.
Additionally, certain models within this series are designed specifically for specialized applications, including use in vacuum environments. These variants are ideal for systems involving vacuum gripping or vacuum fixtures, expanding the valve’s functionality to meet niche industrial needs.
Support and Services:
Our Pneumatic Solenoid Valve product is designed to deliver reliable and efficient performance in various industrial automation applications. For optimal operation, ensure that the valve is installed according to the specified orientation and connection guidelines outlined in the user manual.
Before installation, verify that the supply voltage matches the valve’s rated voltage and that the air supply is clean and dry, with appropriate pressure levels as recommended. Regular maintenance includes periodic inspection for leaks, cleaning of the valve components, and checking electrical connections to prevent malfunction.
If the valve exhibits irregular operation such as failure to actuate, excessive noise, or air leakage, consult the troubleshooting section of the manual for guidance. Common issues may be resolved by cleaning or replacing the coil, checking the power supply, or ensuring that the air lines are free of contaminants.
For optimal longevity, avoid exposure to corrosive substances and extreme environmental conditions beyond the valve’s specifications. Replacement parts and accessories are available to support ongoing maintenance and repair needs.
Our technical support team is committed to assisting customers with installation, operation, and maintenance inquiries to ensure seamless integration and performance of the Pneumatic Solenoid Valve within your systems.
Packing and Shipping:
Product Packaging and Shipping for Pneumatic Solenoid Valve
Each pneumatic solenoid valve is carefully packaged to ensure protection during transit. The valve is first wrapped in anti-static foam or bubble wrap to prevent damage from shocks and vibrations. It is then placed inside a sturdy cardboard box with additional padding materials to secure it firmly in place.
The packaging box is labeled with product details, handling instructions, and fragile warnings to ensure careful handling. For bulk orders, multiple units are packed in a larger carton with dividers to avoid contact between valves.
Shipping options include air freight, sea freight, and express courier services, depending on customer requirements and delivery timelines. All shipments are tracked with a tracking number provided to the customer for real-time updates. We ensure timely delivery and maintain the integrity of the product throughout the shipping process.
