Product Description:
The Eye Bolt, which is also referred to as a Fish Eye Bolt or Live Joint Screw, serves as a highly adaptable hardware fastener. It is specifically designed to provide flexible yet secure connections. One end of this bolt features a precisely machined circular eye, while the opposite end contains a shank that is either fully or partially threaded.
Constructed from durable, high-strength materials such as 304 Stainless Steel or Carbon Steel (Q235), this bolt delivers outstanding resistance to corrosion and long-lasting reliability. It performs exceptionally well even in challenging conditions. Additionally, the Eye Bolt is manufactured in accordance with stringent standards, including GB/T 798-1988 (Chinese National Standard) and DIN 444 (German Industrial Standard), guaranteeing accurate dimensions and thread quality.
Available in a broad spectrum of sizes, with thread diameters ranging from M6 up to M64, this product can accommodate a variety of project requirements. Its versatile design makes it an excellent option for uses that involve pivot points, adjustable angles, or dependable lifting points. Furthermore, the Eye Bolt facilitates quick and easy connection and disconnection, making it a crucial component for both industrial applications and general-purpose tasks.
Features:
Premium Material Options: Our products are available in high-quality 304 Stainless Steel (A2), which provides excellent resistance to rust and corrosion. Alternatively, Carbon Steel (Q235) is offered with protective surface treatments such as black oxide coating or hot-dip galvanizing, ensuring enhanced durability and long-lasting performance.
High Strength: Crafted from robust materials, these components deliver exceptional tensile strength and durability. Carbon steel options come in strength grades 4.8, 8.8, and 10.9, while stainless steel is available in grade A2-70, catering to a variety of mechanical requirements.
Precision Engineering: Manufactured in compliance with stringent GB798 and DIN444 standards, each unit features a smoothly finished spherical surface and accurately cut, high-precision threads to ensure reliable and secure fastening.
Versatile Threading Options: To meet diverse fastening demands, the products are offered in both fully threaded and partially threaded variants, providing flexibility for different application scenarios.
Versatile Design: The circular eye design permits easy attachment to pins, chains, or ropes, allowing for flexible rotation and angular adjustments to accommodate various operational needs.
Technical Parameters:
| Standard |
GB/T 798-1988, DIN 444 |
| Surface Finish |
Bright, Smooth, With Minimal Burrs |
| Thread Diameter |
M6, M8, M10, M12, M16, M20 Up To M30 |
| Thread Pitch |
Standard |
| Nominal Length |
30mm To 200mm |
| Material |
Stainless Steel 304, Carbon Steel |
| Mon |
M5 |
M6 |
M8 |
M10 |
M12 |
M16 |
M20 |
M24 |
M27 |
M30 |
| P |
0.8 |
1 |
1.25 |
1.5 |
1.75 |
2 |
2.5 |
3 |
3 |
3.5 |
| d1 max |
5.03 |
6.03 |
8.036 |
10.036 |
12.043 |
16.043 |
18.043 |
22.052 |
25.052 |
28.052 |
| d1 min |
5 |
6 |
8 |
10 |
12 |
16 |
18 |
22 |
25 |
28 |
| dk max |
12 |
14 |
18 |
20 |
25 |
32 |
40 |
45 |
50 |
55 |
| dk min |
10.9 |
12.9 |
16.9 |
18.7 |
23.7 |
30.4 |
38.4 |
43.4 |
48.4 |
53.1 |
| s max |
8 |
9 |
11 |
14 |
17 |
19 |
24 |
28 |
30 |
34 |
| s min |
7.52 |
8.52 |
10.3 |
13.3 |
16.3 |
18.16 |
23.16 |
27.16 |
29.16 |
33 |
| ds max |
5 |
6 |
8 |
10 |
12 |
16 |
20 |
24 |
27 |
30 |
