Product Description:
The Eye Bolt, commonly referred to as a Fish Eye Bolt or Live Joint Screw, is a highly adaptable hardware fastener engineered to provide both flexible and secure connections. It is characterized by a precisely machined circular eye at one end, paired with a shank that is either fully or partially threaded on the opposite side.
Constructed from robust materials such as 304 Stainless Steel or Carbon Steel (Q235), this bolt delivers superior corrosion resistance and long-lasting durability. Its reliable performance even in challenging environments makes it a preferred choice in various industries. The manufacturing process adheres strictly to standards like GB/T 798-1988 (Chinese National Standard) and DIN 444 (German Industrial Standard), guaranteeing accurate dimensions and thread precision.
Available in a broad range of sizes, with thread diameters ranging from M6 up to M64, the Eye Bolt is versatile enough to accommodate diverse project requirements. This fastener is especially suitable for applications needing a pivot point, adjustable angles, or secure lifting points. Its design facilitates quick attachment and detachment, establishing it as an essential component for both industrial settings and general-purpose uses.
Features:
Premium Material Options: Our products are crafted from high-quality 304 Stainless Steel (A2), providing excellent resistance to rust and corrosion. Alternatively, Carbon Steel (Q235) is offered with specialized surface treatments such as black oxide coating or hot-dip galvanizing to boost durability and protect against wear.
High Strength: Each item is forged from strong materials to ensure exceptional tensile strength and long-lasting performance. The available strength grades include 4.8, 8.8, and 10.9 for carbon steel variants, while stainless steel options come in A2-70 grade, catering to a range of strength requirements.
Precision Engineering: Manufactured in strict accordance with GB798 and DIN444 standards, these components feature a smooth spherical surface and finely crafted high-precision threads to guarantee reliable and accurate assembly.
Versatile Threading Options: To meet diverse fastening needs, the products are available in both fully threaded and partially threaded configurations, allowing for flexibility in various applications.
Versatile Design: The circular eye design facilitates easy connection with pins, chains, or ropes. This allows for smooth rotation and angular adjustments, making the product highly adaptable to different operational scenarios.
Technical Parameters:
| Thread Diameter |
M6, M8, M10, M12, M16, M20 Up To M30 |
| Material |
Stainless Steel 304, Carbon Steel |
| Standard |
GB/T 798-1988, DIN 444 |
| Nominal Length |
60mm To 300mm |
| Surface Finish |
Bright, Smooth, With Minimal Burrs |
| Thread Pitch |
Standard |
| Mon |
M5 |
M6 |
M8 |
M10 |
M12 |
M16 |
M20 |
M24 |
M27 |
M30 |
| P |
0.8 |
1 |
1.25 |
1.5 |
1.75 |
2 |
2.5 |
3 |
3 |
3.5 |
| d1 max |
5.03 |
6.03 |
8.036 |
10.036 |
12.043 |
16.043 |
18.043 |
22.052 |
25.052 |
28.052 |
| d1 min |
5 |
6 |
8 |
10 |
12 |
16 |
18 |
22 |
25 |
28 |
| dk max |
12 |
14 |
18 |
20 |
25 |
32 |
40 |
45 |
50 |
55 |
| dk min |
10.9 |
12.9 |
16.9 |
18.7 |
23.7 |
30.4 |
38.4 |
43.4 |
48.4 |
53.1 |
| s max |
8 |
9 |
11 |
14 |
17 |
19 |
24 |
28 |
30 |
34 |
| s min |
7.52 |
8.52 |
10.3 |
13.3 |
16.3 |
18.16 |
23.16 |
27.16 |
29.16 |
33 |
| ds max |
5 |
6 |
8 |
10 |
12 |
16 |
20 |
24 |
27 |
30 |
