Product Description:
The diaphragms for the QBY and QBY3 series air operated diaphragm pumps serve as essential wearable spare parts. These components are specifically designed to fit various models of air double diaphragm pumps, including QBY-15, QBY-25, QBY-40, QBY-50, QBY-65, QBY-80, QBY-100, as well as QBY3-15, QBY3-20, QBY3-25, QBY3-32, QBY3-40, QBY3-50, QBY3-65, QBY3-80, QBY3-100, and QBY3-125.
Featuring a white F46 material composition, this diaphragm is available in a diverse array of outer diameters and hole patterns. The range of outer diameters includes 125MM, 140MM, 170MM, 225MM, 230MM, 275MM, 300MM, 330MM, 340MM, 365MM, 420MM, and 450MM. Additionally, customers can select from configurations such as 6 holes, 8 holes, 10 holes, no hole, or a center hole with a 92MM diameter, allowing compatibility with a variety of pump models and equipment.
Constructed from F46 material, the diaphragm exhibits exceptional resistance to corrosion caused by acids, alkalis, and other chemically corrosive fluids. This durability ensures a stable and long service life, making it a reliable choice for maintenance and replacement purposes. Its easy installation process and broad applicability make it a common standard spare part used extensively in industries such as chemical manufacturing, wastewater treatment, and electroplating.
Features:
The product offers complete specifications that are fully compatible with the QBY and QBY3 pump series. It features multiple outer diameter sizes and various hole configurations, ensuring a perfect fit with the original pump equipment.
Manufactured from F46 material, the diaphragm provides excellent corrosion resistance, effectively withstanding acids, alkalis, and solvents. This makes it highly suitable for use in harsh chemical environments.
With its superior elasticity and outstanding anti-fatigue properties, the diaphragm resists cracking even under repeated reciprocating motions. This durability helps to significantly extend the service life of the pump.
The component boasts high dimensional accuracy and stable sealing performance, allowing for easy installation. It can be directly replaced to substitute worn diaphragms without any hassle.
Designed as an industrial-grade spare part for AODD pumps, it is ideal for self-priming transfer applications and the delivery of high-flow corrosive liquids.
Technical Parameters:
| Product Name |
QBY K Air Operated Diaphragm Pump Diaphragm |
| Hole Type |
6 Holes, 8 Holes, 10 Holes, No Hole, Center Hole 92MM |
| Material |
F46 White |
| Applicable Pump |
QBY Series, QBY3 Series Air Operated Diaphragm Pump |
| Function |
Wear Replacement Spare Part for Air Diaphragm Pump |
| Outer Diameter |
125MM, 140MM, 170MM, 225MM, 230MM, 275MM, 300MM, 330MM, 340MM, 365MM, 420MM, 450MM |
Applications:
Chemical Industry
This sector involves the transportation of various corrosive chemical liquids, ensuring safe and efficient delivery within the production process.
Wastewater Treatment
In wastewater treatment, the focus is on transferring sewage sludge slurry, maintaining proper handling to support effective processing and disposal.
Electroplating Industry
The electroplating industry requires the circulation and transfer of electroplating liquids, which are essential for coating processes and maintaining quality standards.
Coating & Ink Industry
This field deals with the movement of paint and dye fluids, facilitating smooth application and production of coatings and inks.
Mining Industry
Mining operations often involve the delivery of slurry and corrosive pulp, which must be handled carefully to ensure operational efficiency and safety.
Pharmaceutical Industry
The pharmaceutical sector requires the transfer of corrosive raw materials, demanding precision and safety in handling to maintain product integrity.
Support and Services:
Our Pulse Valve Diaphragm is designed to deliver reliable performance and long service life in demanding industrial applications. To ensure optimal operation, it is important to use genuine replacement diaphragms and follow proper installation procedures.
When installing the diaphragm, make sure the valve is depressurized and clean to prevent contamination. Inspect the diaphragm for any signs of damage or defects before installation. Align the diaphragm correctly to avoid leaks and ensure proper sealing.
Regular maintenance and inspection of the pulse valve diaphragm are recommended to prevent unexpected downtime. Replace the diaphragm if you notice any cracks, tears, or excessive wear that could affect valve performance.
For technical support, troubleshooting guidance, and detailed installation instructions, please refer to the product manual or contact our support team. We are committed to providing comprehensive assistance to help you maintain the efficiency and reliability of your pulse valve systems.
Packing and Shipping:
Each Pulse Valve Diaphragm is carefully packaged to ensure maximum protection during transit. The diaphragm is first placed in a protective plastic sleeve to prevent any contamination or damage. It is then securely positioned within a custom-fitted cardboard box, designed to minimize movement and absorb shocks.
For shipping, we use sturdy outer cartons with cushioning materials such as foam or bubble wrap to provide additional protection. All packages are clearly labeled with handling instructions to ensure careful treatment throughout the shipping process.
We offer various shipping options to meet your delivery needs, including standard, expedited, and freight services. Tracking information is provided with every shipment to allow you to monitor your order from our facility to your doorstep.
Our packaging and shipping processes are designed to guarantee that your Pulse Valve Diaphragm arrives in perfect condition, ready for immediate installation and use.
