Product Description:
Design Features
The design of this product includes several features that make it stand out in terms of functionality and ease of use. One of the main advantages of this product is that it features a floating joint design that allows for the absorption of eccentricity between the passive body and the cylinder. Additionally, this design can compensate for the insufficient accuracy of parallelism without requiring axis alignment, simplifying the installation process.
Another key feature of this product is its high temperature specification range. It is designed to operate in environments ranging from -5 ℃ to 60 ℃, ensuring that this product maintains a stable connection under extreme temperatures.
Lastly, this product boasts a high load handling capacity, with the ability to handle a maximum applied tensile force of 28000 N on both the compression and tension sides, demonstrating excellent load bearing capacity.
Technical Specifications
This product comes in a basic type installation form, providing a stable connection method 2. It is suitable for a cylinder with a diameter of 100mm and has a standard M26X1.5 thread specification, making it easy to connect with cylinders and other pneumatic components.
The swing angle for this product is ± 5 °, allowing for a certain eccentricity of 0.5mm, providing greater flexibility and adaptability to varied operational requirements.
With a pressure range of 0.05-1 MPa, this product is suitable for various working pressures. Additionally, it can operate in environmental and fluid temperatures ranging from -5~60 ℃, making it highly versatile and practical for various working environments.
Technical Parameters:
| Attribute |
Value |
| Connection |
Flange |
| Cylinder Used |
Air Cylinder / Hydraulic Cylinders |
| Color |
Black |
| Series |
JA Series |
| Type |
Fittings |
| Connection Type Cylinder Side |
Tapped |
| Applicable Cylinder Thread Size |
JA Series |
Applications:
Application scenarios:
Pneumatic and hydraulic systems: SMC’s JA series floating joints are suitable for connecting cylinders and hydraulic cylinders, especially in situations where eccentricity and parallelism need to be absorbed. With their flexible design, they provide an efficient connection solution for pneumatic systems.
Automated machinery: JA series floating joints are used in automated machinery to connect cylinders and driven bodies, ensuring stable system operation. They help to provide reliable and efficient performance.
Handling system: JA series floating joints ensure stable operation of cylinders in the handling system to improve handling efficiency. They are designed to provide reliable and efficient performance in handling systems.
Market positioning and user evaluation:
Market positioning: SMC's JA series floating joints provide an efficient and flexible connection solution for pneumatic systems with their excellent design and performance. They are widely used in the field of industrial automation, providing an effective solution for connecting pneumatic and hydraulic systems.
User evaluation: Users have given high praise to SMC's JA series floating joint, believing that it performs well in absorbing eccentricity and insufficient parallelism, tolerating high temperatures, and providing high load response ability. Thanks to their stable and reliable pneumatic connection solution, they are considered as a preferred choice for many users.
Summary:
SMC's JA series floating joints are an efficient and reliable solution for connecting pneumatic and hydraulic systems. With their flexible design, they offer an effective solution for absorbing eccentricity and parallelism, and are popular among users working in industrial automation. They help to streamline operation, ensuring a reliable and efficient performance for handling systems.
