Product Description:
When it comes to design features, this particular floating joint provides a solution to the insufficient absorption of eccentricity and parallelism. It is specially engineered to absorb the eccentricity between the passive body and cylinder, as well as any insufficient parallelism, without the need for axis alignment. This simplifies the installation process, saving time and effort.
Furthermore, this floating joint features a high-temperature specification, making it suitable for use within environments ranging from -5 ℃ to 60 ℃. This ensures that the connection remains stable even when subjected to extreme temperatures.
Another noteworthy design feature is the high load handling capacity. The maximum applied tensile force on both the compression and tension sides is 28,000 N, demonstrating excellent load-bearing capacity.
As for the technical specifications, the installation form is a basic type that provides a stable connection method 2. It is designed to suit cylinder 1 with a diameter of 100mm, and the thread specification used is M26X1.5, a standard thread specification that makes it easy to connect with cylinders and other pneumatic components.
The swing angle is ± 5 °, allowing for a certain eccentricity of up to 0.5mm, providing greater flexibility and adaptability. This floating joint is also suitable for various working pressures, with a pressure range of 0.05-1 MPa. Additionally, it is designed to be used within various working environments, with both environmental and fluid temperature ranging between -5~60 ℃.
Technical Parameters:
| Attribute |
Value |
| Type |
Fittings |
| Color |
Black |
| Connection Type Cylinder Side |
Tapped |
| Series |
JA Series |
| Cylinder Used |
Air Cylinder / Hydraulic Cylinders |
| Connection |
Flange |
SMC JA Series Floating Joints, Cylinder exhaust tailpipe joint, SMC floating joint
Applications:
Pneumatic and hydraulic systems can benefit from utilizing SMC's JA series floating joints. These joints are particularly suitable for connecting cylinders and hydraulic cylinders, especially in situations where eccentricity and parallelism need to be absorbed. The floating joints ensure a stable and flexible connection, improving the overall performance of the system.
Automated machinery requires precision and stability to ensure efficient operation. The JA series floating joints are commonly used in connecting cylinders and driven bodies, ensuring that the system operates smoothly and reliably. By utilizing the floating joints, automated machinery can achieve higher levels of productivity while reducing the risk of downtime due to faults or malfunctions.
In handling systems, the JA series floating joints ensure a stable operation of cylinders, which in turn improves handling efficiency. Whether in manufacturing plants or logistics centers, quick and efficient handling systems are essential in maintaining the smooth flow of materials and goods. By using SMC's floating joints, the handling system can operate with greater consistency and reliability.
SMC's JA series floating joints are well-positioned in the market, providing an efficient and flexible connection solution for pneumatic systems. Their excellent design and performance make them a popular choice in the field of industrial automation. The JA series floating joints are widely used in connecting cylinders and hydraulic cylinders, and other components of pneumatic systems.
Users have highly praised the performance of SMC's JA series floating joint. The floating joints can absorb eccentricity and insufficient parallelism, tolerate high temperatures, and respond to heavy loads. Users have experienced the benefits of a stable and reliable pneumatic connection solution, which enables them to operate their systems with greater confidence and efficiency.
In summary, SMC's JA series floating joints provide an efficient and reliable solution for connecting pneumatic and hydraulic systems. With their excellent design and performance, they are widely used in the field of industrial automation. The JA series floating joints ensure that cylinders and other components operate with greater consistency and reliability, improving overall system performance.
