Product Description:
Design Features:
The floating joint design of this product is highly efficient in absorbing both eccentricity and parallelism. It facilitates easy connection between the passive body and the cylinder without requiring axis alignment. With the floating joint design, the installation process is more simplified, saving your time and effort.
This product is designed to work optimally even in extreme temperatures. It is suitable for temperatures ranging from -5℃ to 60℃, ensuring connectivity stability and durability in any working environment.
If you’re looking for a product that can handle high loads, this is the perfect fit for you. With a tensile strength capacity of 28000 N on both the compression and tension sides, this product demonstrates excellent load-bearing capacity.
Technical Specifications:
The basic type installation form provides stable connection.
This product is suitable for cylinders with 100mm diameter.
The thread specification for this product is M26X1.5, making it easy to connect with cylinders and other pneumatic components.
The swing angle of this product is ± 5°, allowing a certain eccentricity of 0.5mm and providing greater flexibility and adaptability.
It can handle pressures ranging from 0.05-1 MPa, making it suitable for various working pressures.
With an environmental temperature range of -5~60℃ and fluid temperature range, this product can efficiently function in various working environments.
Technical Parameters:
| Series |
JA Series |
| Connection |
Flange |
| Cylinder Used |
Air Cylinder / Hydraulic Cylinders |
| Color |
Black |
| Type |
Fittings |
| Connection Type Cylinder Side |
Tapped |
| Additional Information |
SMC JA Series Floating Joints. Applicable cylinder thread size: taille de filetage de cylindre applicable |
Applications:
Pneumatic and hydraulic systems require connectors that can absorb eccentricity and parallelism, making SMC's JA series floating joints excellent choices for connecting cylinders and hydraulic systems.
In automated machinery, these connectors ensure stable operation of systems by connecting cylinders and driven bodies.
Additionally, when used in handling systems, SMC's JA series floating joints help improve the handling efficiency of cylinders by providing stable operation.
Market positioning: SMC's JA series floating joints are designed to provide efficient and flexible connection solutions for pneumatic systems, making them widely used in the field of industrial automation.
User evaluation: Users have highly praised SMC's JA series floating joints for their ability to absorb eccentricity and insufficient parallelism, high temperature tolerance, and high load response ability. These joints provide a stable and reliable pneumatic connection solution that many users trust.
Overall, the excellent design and performance of SMC's JA series floating joints make them an efficient and reliable solution for connecting pneumatic and hydraulic systems, and they are trusted by many users in the field of industrial automation.
