Product Description:
Design Features:
The floating joint design of this product can absorb the eccentricity between the passive body and the cylinder, as well as the insufficient accuracy of parallelism, without requiring axis alignment. This simplifies the installation process and ensures a stable connection. Additionally, this product is capable of working under extreme temperatures ranging from -5°C to 60°C, ensuring connection stability. Lastly, it is built to handle high loads with a maximum tensile force of 28000 N, demonstrating excellent load bearing capacity.
Technical Specifications:
This product comes in a basic type, providing a stable connection method 2 to make installation easier. It is suitable for cylinders with a diameter of 100mm and has a standard thread specification of M26X1.5 that enables easy connection to pneumatic components. With a swing angle of ± 5° and the ability to handle eccentricity of up to 0.5mm, it provides greater flexibility and adaptability. Lastly, it can operate in a pressure range of 0.05-1 MPa and is capable of withstanding various working environments with temperatures ranging from -5°C to 60°C.
Technical Parameters:
| Cylinder Used |
Air Cylinder / Hydraulic Cylinders |
| Series |
JA Series |
| Connection |
Flange |
| Connection Type Cylinder Side |
Tapped |
| Color |
Black |
| Type |
Fittings |
This product is suitable for use with Hydraulic cylinder floating joint and belongs to the JA Series.
| JA6-3-050 |
JA80-20-150 |
| JA10-4-070 |
JA80-20-250 |
| JA15-5-080 |
JA80-22-150 |
| JA15-6-100 |
JA100-24-300 |
| JA20-8-100 |
JA100-26-150 |
| JA20-8-125 |
JA100-27-150 |
| JA20-8-150 |
JA100-27-200 |
| JA25-10-150 |
JA125-27-200 |
| JA30-10-125 |
JA140-30-150 |
| JA32-10-100 |
JA160-30-200 |
| JA40-12-125 |
JA160-33- 200 |
| JA40-12-150 |
JA160-36-150 |
| JA40-12-175 |
JA160-36-200 |
| JA40-14-125 |
JA180-40-150 |
| JA40-14-150 |
JA180-40-200 |
| JA63-16-150 |
JA180-42-150 |
| JA63-16-200 |
JA180-42-200 |
| JA63-18-150 |
|
Applications:
Pneumatic and Hydraulic Systems
The JA series floating joints from SMC are ideal for connecting cylinders and hydraulic cylinders, especially in situations where there is a need for eccentricity and parallelism absorption. The floating joints provide an efficient and flexible connection solution for pneumatic systems in industrial automation.
Automated Machinery
In automated machinery, the JA series floating joint is used to connect cylinders and driven bodies to ensure the stable operation of the system. The floating joint's ability to absorb eccentricity and parallelism makes it an ideal choice for automated machinery and ensures the stability of the system.
Handling System
The handling system requires stable operation of cylinders to improve handling efficiency. SMC's JA series floating joint can provide this stability, making it an excellent choice for handling system applications.
Market Positioning and User Evaluation
The JA series floating joints from SMC are highly valued for their excellent design and performance, and are widely used in industrial automation. Market positioning for these floating joints is based on their ability to provide efficient and flexible connection solutions for pneumatic systems.
Users have given high praise to SMC's JA series floating joints. These floating joints perform well in absorbing eccentricity and insufficient parallelism. They have a high temperature tolerance and high load response ability, providing users with a stable and reliable pneumatic connection solution.
In summary, SMC's JA series floating joints provide an efficient and reliable solution for connecting pneumatic and hydraulic systems with their excellent design and performance. They are widely used in the field of industrial automation, making them an ideal choice for various industrial applications.
