Product Description:
Design Features:
The floating joint design of this product can effectively absorb the eccentricity between the passive body and the cylinder, as well as the insufficient accuracy of parallelism. This eliminates the need for axis alignment and simplifies the installation process.
In addition, the product is suitable for working environments ranging from -5 ℃ to 60 ℃, ensuring connection stability under extreme temperatures. It also has an excellent load bearing capacity, with a maximum applied tensile force of 28000 N on both the compression and tension sides.
Technical Specifications:
This product comes in a basic installation form, providing a stable connection method 2. It is designed to work with cylindrical objects that have a diameter of 100mm, and it features a standard thread specification of M26X1.5. This makes it easy to connect with cylinders and other pneumatic components.
The product also allows for a swing angle of ±5°, which enables it to accommodate a certain eccentricity of up to 0.5mm. Furthermore, it is suitable for a pressure range between 0.05-1 MPa, making it ideal for various working pressures. The environmental temperature and fluid temperature range is between -5~60 ℃, allowing it to function effectively in a wide range of working environments.
Technical Parameters:
| Color |
Black |
| Connection Type Cylinder Side |
Tapped |
| Connection Type |
Flange |
| Type |
Fittings |
| Cylinder Used |
Air Cylinder / Hydraulic Cylinders |
| Series |
JA Series |
Hydraulic cylinder floating joint compatible with the SMC JA Series Floating Joints.
Applications:
Pneumatic and Hydraulic Systems
Suitable for connecting cylinders and hydraulic cylinders, especially in situations where eccentricity and parallelism need to be absorbed, pneumatic and hydraulic systems play an essential role in the field of industrial automation. To ensure the system's stable operation, it is necessary to use high-quality connection solutions such as floating joints.
Automated Machinery
In automated machinery, connection solutions such as floating joints are used to connect cylinders and driven bodies, thereby ensuring the stable operation of the system. By providing reliable connections, floating joints contribute towards the efficiency and productivity of automated machinery.
Handling Systems
The handling system requires the stable operation of cylinders to improve efficiency. Therefore, the use of floating joints ensures the smooth and reliable operation of cylinders, thus contributing to an improvement in handling efficiency.
Market Positioning and User Evaluation
SMC's JA series floating joints have an excellent design and performance which provide efficient and flexible connection solutions for pneumatic systems. As a result, they have a prime market positioning in the field of industrial automation.
Users have given high praise to SMC's JA series floating joints, reporting that they perform well in absorbing eccentricity and insufficient parallelism, temperature tolerance, and load response ability. SMC's floating joints provide users with a stable and reliable pneumatic connection solution, making them a popular choice in the industry.
In summary, SMC's JA series floating joints offer an efficient and reliable solution for connecting pneumatic and hydraulic systems. Their excellent design and performance have made them a trusted name in the industry, with widespread use in the field of industrial automation.
