Product Description:
Design Features
The floating joint design is a unique feature of this product that is capable of absorbing eccentricity and parallelism. This means that it can deal with insufficient accuracy of parallelism and eccentricity between the passive body and the cylinder without requiring any axis alignment. This simplifies the installation process, making it easy for users to get up and running quickly.
The product has a high temperature specification, making it suitable for use in a broad range of environments. It can handle temperatures ranging from -5 ℃ to 60 ℃, which ensures connection stability in extreme weather conditions.
A key highlight of this product is its high load handling capacity. It can comfortably handle a maximum applied tensile force of 28000 N, proving that it can bear a significant load.
Technical Specifications
The product comes in a basic type installation form, which provides a stable connection method 2. It is suitable for use with cylinders that have a diameter of 100mm. Its thread specification is M26X1.5, which is a standard thread specification that makes it easy to connect with cylinders and other pneumatic components.
One of the strengths of this product is its swing angle, which allows for a swing of ± 5 degrees, allowing for a certain degree of eccentricity of up to 0.5mm. This provides greater flexibility and adaptability in different use-case scenarios. It is suitable for use under pressure ranges of 0.05-1 MPa and can handle various working pressures with ease. Finally, it can operate in environmental temperatures and fluid temperatures ranging from -5~60 ℃, making it a versatile product for use across different industries.
Technical Parameters:
| Connection |
Flange |
| Connection Type Cylinder Side |
Tapped |
| Cylinder Used |
Air Cylinder / Hydraulic Cylinders |
| Color |
Black |
| Type |
Fittings |
| Series |
JA Series |
Applications:
Pneumatic and hydraulic systems:
SMC's JA series floating joints are suitable for connecting cylinders and hydraulic cylinders, especially in situations where eccentricity and parallelism need to be absorbed. These joints ensure stable operation of cylinders, improve handling efficiency, and enhance performance in automated machinery.
Automated machinery:
The JA series floating joint is used in automated machinery to connect cylinders and driven bodies to ensure stable operation of the system. This enhances the efficiency of the automated machinery by providing a reliable pneumatic connection solution.
Handling system:
The JA series floating joint ensures stable operation of cylinders in the handling system, thereby improving handling efficiency. The joint absorbs eccentricity and ensures parallelism, which is critical when handling delicate materials.
Market positioning and user evaluation:
Market positioning:
The JA series floating joints from SMC offer an excellent and flexible connection solution for pneumatic systems. These joints have a smart design and performance, and they are widely used in industrial automation.
User evaluation:
Users have given high praise to SMC's JA series floating joint for their excellent tolerance for high temperatures and high load response ability. The joint provides users with a stable and reliable pneumatic connection solution that performs well in absorbing eccentricity and insufficient parallelism.
In summary,
SMC's JA series floating joints provide an efficient and reliable solution for connecting pneumatic and hydraulic systems. This is due to their excellent design and performance, making them widely used in the field of industrial automation.
Packing and Shipping:
Product Name: SMC Solenoid Valves
Packaging: The SMC Solenoid Valves are carefully packaged in a sturdy cardboard box with appropriate cushioning materials to prevent any damage during transit. Each unit is individually wrapped and sealed to ensure maximum protection.
Shipping: We offer both domestic and international shipping options for the SMC Solenoid Valves. For domestic shipping, we use reliable courier services with tracking information provided to the customer. For international shipping, we partner with trusted logistics companies to ensure timely delivery and minimal customs delays. Shipping charges will be calculated at the time of checkout based on the destination and shipping method selected by the customer.
