Place of Origin: | China |
Brand Name: | SMC |
Certification: | CE |
Model Number: | SY5320-5LZD-C6 |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiation |
Packaging Details: | Carton /As The Clients Require |
Delivery Time: | 1-7Work Days After Payment |
Payment Terms: | T/T, Western Union,Paypal |
Supply Ability: | 5000 pieces/1Month |
Mounting Orientation: | Unrestricted | Indicator Light: | LED |
---|---|---|---|
Lubrication: | Not Required | Impact/Vibration Resistance (m/s2 ): | 150/30 |
Enclosure: | Dust Proof | Allowable Voltage Fluctuation: | ±10% Of Rated Voltage |
Highlight: | 3 Position SMC Solenoid Valve,SY5320-5LZD-C6,DC24V SMC Solenoid Valve |
The Series SY is a great advancement in valve performance. It offers cost-effective solutions that cater to your specific needs and requirements. Thanks to its compact design, the series boasts a high flow capacity while consuming low amounts of power.
What makes the SY series stand out is its versatility. It is suitable for a variety of applications, making it a top choice for different industries. The valve is available in two different styles, namely body ported and base mounted. The flexibility to use it individually or mount it into a manifold arrangement means that you can customize it to suit your requirements.
Commercial, manufacturing, and industrial operations will find that the Series SY is the perfect valve solution for their needs. With its low power consumption and high flow rate, it is an efficient and reliable choice for different applications.
Valve model |
Type of actuation |
Port size | Flow rate characteristics | Weight (g) | ||||||||||
1, 5, 3 (P, EA, EB) |
4, 2 (A, B) |
1→4/2 (P→A/B) | 4/2→5/3 (A/B→EA/EB) | Gro- mmet |
L/M plug connector |
DIN terminal |
W M8 connector |
|||||||
C (dm3/ (s·bar) ) |
b | Cv | C (dm3/ (s·bar) ) |
b | Cv | |||||||||
SY5□20 -□-01 |
2 position |
Single | ![]() ![]() |
18 | 1.9 | 0.35 | 0.49 | 2.4 | 0.39 | 0.61 | 70 | 72 | 93 | 76 |
Double | 88 | 93 | 135 | 101 | ||||||||||
3 position |
Closed center |
1.7 | 0.43 | 0.45 | 1.8 | 0.35 | 0.46 | 93 | 98 | 140 | 106 | |||
Exhaust center |
1.5 | 0.44 | 0.41 | 2.5 (1.5) |
0.32 (0.43) |
0.59 (0.40) |
||||||||
Pressure center |
2.2 (0.91) |
0.46 (0.58) |
0.61 (0.28) |
1.8 | 0.38 | 0.46 | ||||||||
SY5□20 -□-C4 |
2 position |
Single | ![]() ![]() ![]() touch fitting |
0.75 | 0.43 | 0.20 | 0.85 | 0.64 | 0.30 | 94 | 96 | 117 | 100 | |
Double | 111 | 117 | 159 | 125 | ||||||||||
3 position |
Closed center |
0.74 | 0.40 | 0.19 | 0.84 | 0.57 | 0.28 | 117 | 122 | 164 | 130 | |||
Exhaust center |
0.75 | 0.36 | 0.19 | 0.84 (0.84) |
0.64 (0.53) |
0.30 (0.27) |
||||||||
Pressure center |
0.78 (0.71) |
0.44 (0.37) |
0.21 (0.18) |
0.84 | 0.57 | 0.27 | ||||||||
SY5□20 -□-C6 |
2 position |
Single | C6 One- touch fitting for ø6 |
1.5 | 0.33 | 0.33 | 2.0 | 0.37 | 0.52 | 88 | 91 | 112 | 95 | |
Double | 106 | 111 | 153 | 119 | ||||||||||
3 position |
Closed center |
1.3 | 0.31 | 0.33 | 1.6 | 0.32 | 0.39 | 111 | 116 | 158 | 124 | |||
Exhaust center |
1.3 | 0.33 | 0.33 | 1.8 (1.4) |
0.35 (0.37) |
0.44 (0.35) |
||||||||
Pressure center |
1.7 (0.80) |
0.31 (0.47) |
0.42 (0.23) |
1.7 | 0.33 | 0.44 | ||||||||
SY5□20 -□-C8 |
2 position |
Single | ![]() One- touch fitting for ø8 |
1.9 | 0.21 | 0.45 | 2.3 | 0.29 | 0.57 | 80 | 82 | 103 | 86 | |
Double | 98 | 103 | 145 | 111 | ||||||||||
3 position |
Closed center |
1.6 | 0.29 | 0.39 | 1.7 | 0.38 | 0.46 | 103 | 108 | 150 | 116 | |||
Exhaust center |
1.4 | 0.38 | 0.39 | 2.0 (1.5) |
0.37 (0.41) |
0.52 (0.43) |
||||||||
Pressure center |
2.2 (1.6) |
0.32 (0.44) |
0.56 (0.44) |
1.8 | 0.41 | 0.50 |
SY3120-5LZD-M5 | SY3320-5LZD-C4 | SY5120-5LZD-C6 | SY5320-5LZD-C8 |
SY3120-6LZD-M5 | SY3320-6LZD-C4 | SY5120-6LZD-C6 | SY5320-6LZD-C8 |
SY3120-5LZD-C4 | SY3320-5LZD-C6 | SY5120-5LZD-C8 | SY5420-5LZD-01 |
SY3120-6LZD-C4 | SY3320-6LZD-C6 | SY5120-6LZD-C8 | SY5420-6LZD-01 |
SY3120-5LZD-C6 | SY3320-5LZD-C8 | SY5220-5LZD-01 | SY5420-5LZD-C4 |
SY3120-6LZD-C6 | SY3320-6LZD-C8 | SY5220-6LZD-01 | SY5420-6LZD-C4 |
SY3120-5LZD-C8 | SY3420-5LZD-M5 | SY5220-5LZD-C4 | SY5420-5LZD-C6 |
SY3120-6LZD-C8 | SY3420-6LZD-M5 | SY5220-6LZD-C4 | SY5420-6LZD-C6 |
SY3220-5LZD-M5 | SY3420-5LZD-C4 | SY5220-5LZD-C6 | SY5420-5LZD-C8 |
SY3220-6LZD-M5 | SY3420-6LZD-C4 | SY5220-6LZD-C6 | SY5420-6LZD-C8 |
SY3220-5LZD-C4 | SY3420-5LZD-C6 | SY5220-5LZD-C8 | SY7120-5LZD-02 |
SY3220-6LZD-C4 | SY3420-6LZD-C6 | SY5220-6LZD-C8 | SY7120-5LZD-C4 |
SY3220-5LZD-C6 | SY3420-5LZD-C8 | SY5320-5LZD-01 | SY7120-5LZD-C6 |
SY3220-6LZD-C6 | SY3420-6LZD-C8 | SY5320-6LZD-01 | SY7120-5LZD-C8 |
SY3220-5LZD-C8 | SY5120-5LZD-01 | SY5320-5LZD-C4 | SY7220-5LZD-02 |
SY3220-6LZD-C8 | SY5120-6LZD-01 | SY5320-6LZD-C4 | SY7220-5LZD-C4 |
SY3320-5LZD-M5 | SY5120-5LZD-C4 | SY5320-5LZD-C6 | SY7220-5LZD-C6 |
SY3320-6LZD-M5 | SY5120-6LZD-C4 | SY5320-6LZD-C6 | SY7220-5LZD-C8 |
The SMC Solenoid Valve is suitable for different scenarios, such as controlling the flow of liquids or gases in pneumatic systems, medical equipment, and food processing machinery. It can also be used for automatic control systems, for example, in manufacturing plants, automotive applications, and mining operations. The valve's enclosure is dustproof, making it suitable for use in harsh environments where dust particles may be present.
The SMC Solenoid Valve has an unrestricted mounting orientation, which means it can be mounted in any position without compromising its performance. It can withstand voltage fluctuations of up to ±10% of the rated voltage, which makes it reliable in areas with unstable power supply. The valve has been tested for impact and vibration resistance, withstanding up to 150m/s2 and 30m/s2, respectively. The valve's LED indicator light makes it easy to monitor its status and quickly detect any issues.
With a supply ability of 5000 pieces per month, the SMC Solenoid Valve is readily available to meet your needs. It can be purchased using various payment terms, including T/T, Western Union, and Paypal. Contact the supplier today and get the SMC Solenoid Valve for your application needs.
Our SMC Solenoid Valves product comes with comprehensive technical support and services to ensure optimal performance and longevity. Our team of experts is available to answer any questions you may have regarding installation, operation, and maintenance of the product. We also provide assistance in diagnosing and resolving any issues you may encounter with the product.
In addition to technical support, we offer a range of services to help you get the most out of your SMC Solenoid Valves product. These include customization and integration services, as well as training and education programs to help you and your team get up to speed on the product and its applications.
At SMC, we are committed to providing exceptional support and services to our customers. Contact us today to learn more about our SMC Solenoid Valves product and how we can help you get the most out of it.
Product Packaging:
Shipping:
