Product Description:
Properties of JAF Series Floating Joints
The JAF series floating joints have several key features, including:
Design Features:
- Ability to absorb eccentricity and insufficient parallelism accuracy between the cylinder and passive body without requiring axis alignment
- Flange type installation that suits cylinders with various diameters
- High pressure resistance performance for cylinders and hydraulic cylinders, up to 1MPa and 3.5MPa, respectively
- Excellent sealing material made of resin, which is resistant to chemicals and heat
- Large swing angle that allows for eccentricity and swing angle, providing greater flexibility and adaptability
Technical Specifications:
- Connection diameter: Rc1/4 or M27X1.5
- Fluids used: compressed air and water to meet various fluid control needs
- Pressure range: 0.05-1 MPa, suitable for various working pressures
- Environmental temperature and fluid temperature range: -5 to 60 ℃, suitable for various working environments
- Maximum tensile strength: For example, the maximum tensile strength of JAF100-27-150 is 28000 N2
- Allowable eccentricity and swing angle: generally ± 5 °, with a certain installation error of 12
- Dust cover material: synthetic rubber, providing good sealing and dust-proof performance
Technical Parameters:
| Specifications: |
M20x1.5 Nominal Size |
| Type: |
Floating Joints |
| Cylinder Used: |
Air Cylinder |
| Product Type: |
Simple |
| Brand: |
SMC® |
| Series: |
JAF |
| Description: |
SMC floating joints, JAF series with flange, SMC aluminum floating joint |
Applications:
Application Scenarios:
The product is ideal for connecting hydraulic cylinders and cylinders in situations where there is lack of eccentricity and parallelism to be accommodated. This makes it highly suitable for use in a variety of scenarios such as automated machinery, precision positioning equipment, material handling systems, robotic arm connections, and assembly line automation.
The hydraulic cylinder couplings are designed to be highly versatile, which make it an efficient and cost-effective solution for companies that need to connect hydraulic cylinders and cylinders for their operations. The couplings are made from high-quality materials, which ensures that they can withstand extreme loads, ensuring durability and reliability. The product can be customized to fit specific user requirements, making it a highly flexible option for a wide range of applications.
Whether you're looking to connect hydraulic cylinders for precision positioning systems or cylinder connections for material handling systems, the hydraulic cylinder couplings are a highly effective solution that are designed to provide seamless integration. With a proven track record of performance and reliability, the product is trusted by businesses across industries to deliver excellent results.
If you're looking for a high-quality hydraulic cylinder coupling for your operations, get in touch with us today to learn more about our product offerings and how we can help you find the right solution for your needs.
