SMC JAF63-18-150 Aluminum Floating Joint Air Cylinder Solution

Product Description:

The JAF series floating joints are designed with the following features:

Insufficient Absorption of Eccentricity and Parallelism: The JAF series floating joint can absorb eccentricity and insufficient parallelism accuracy between the cylinder and the passive body without the need for axis alignment. This reduces the demand for high-precision machining, providing a cost-effective solution for fluid control.

Flange Type Installation: The floating joint adopts a flange type installation form, which is suitable for cylinders with different diameters. It provides stable connection and convenient installation, ensuring the efficiency of fluid control.

High Pressure Resistance Performance: The JAF series floating joint is suitable for cylinders and hydraulic cylinders, with a cylinder pressure range of up to 1MPa and hydraulic cylinder pressure up to 3.5MPa. This feature makes it ideal for use in high-pressure fluid control environments.

Excellent Sealing Material: The main material used in JAF series floating joints is resin, which has good chemical and heat resistance. This ensures reliable sealing and extends the life of the equipment.

Large Swing Angle: The floating joint allows for a certain amount of eccentricity and swing angle, providing greater flexibility and adaptability in fluid control applications.

The JAF series floating joints have the following technical specifications:

Connection Diameter: Rc1/4 or M27X1.5, etc., suitable for various pipe diameter requirements.

Using Fluids: Compressed air and water can be used to meet a wide range of fluid control needs.

Pressure Range: The floating joint is suitable for various working pressures, with a pressure range of 0.05-1 MPa.

Environmental Temperature and Fluid Temperature Range: The JAF series floating joint can be used in various working environments, with an environmental temperature and fluid temperature range of -5 to 60 ℃.

Maximum Tensile Strength: For example, the maximum tensile strength of JAF100-27-150 is 28000 N ².

Allowable Eccentricity and Swing Angle: Generally ± 5 °, with a certain installation error of 12.

Dust Cover Material: The dust cover is made of synthetic rubber, providing good sealing and dust-proof performance for the floating joint.

Technical Parameters:

SMC JAF series aluminum floating joint, JAF series with flange, SMC JAF series aluminum floating joint

Applications:

Application scenarios include connecting cylinders and hydraulic cylinders, particularly in situations where eccentricity and parallelism are not sufficient to be absorbed. These couplings offer a variety of benefits and are widely used in many fields, including automated machinery, robotics arm connections, material handling systems, precision positioning equipment, and assembly line automation.

The couplings are designed to offer robust and reliable performance, even in demanding and challenging environments. They are flexible in nature, which makes them ideal for connecting equipment and systems that undergo frequent vibration or shock.

Moreover, the couplings are easy to install, and they require minimal maintenance, which makes them an ideal choice for applications where uptime is critical. They can be customized to meet specific application requirements, such as torque, speed, and misalignment, among others.

In conclusion, these couplings offer the perfect solution for industries that require reliable and efficient connections between cylinders and hydraulic cylinders. With their flexibility, reliability, and ease of installation, they are an essential component in automated machinery, robotics, material handling systems, precision positioning equipment, and assembly line automation.
