Product Description:
Design Features:
The JAF series floating joint has several design features that make it a reliable and convenient solution for connection of cylinders and hydraulic cylinders. These features include:
- Insufficient Absorption of Eccentricity and Parallelism: The floating joint can absorb eccentricity and insufficient parallelism accuracy between the cylinder and the passive body, reducing the demand for high-precision machining.
- Flange Type Installation: Adopting a flange type installation form, the floating joint is suitable for cylinders with different diameters, providing stable connection and convenient installation.
- High Pressure Resistance Performance: The floating joint is suitable for cylinders and hydraulic cylinders, with cylinder pressure up to 1MPa and hydraulic cylinder pressure up to 3.5MPa.
- Excellent Sealing Material: The main material is resin, which has good chemical and heat resistance.
- Large Swing Angle: The floating joint allows for a certain amount of eccentricity and swing angle, providing greater flexibility and adaptability.
Technical Specifications:
The JAF series floating joint has the following technical specifications:
- Connection Diameter: Rc1/4 or M27X1.5, etc., suitable for various pipe diameter requirements.
- Using Fluids: Compressed air and water to meet various fluid control needs.
- Pressure Range: 0.05-1 MPa, suitable for various working pressures.
- Environmental Temperature and Fluid Temperature Range: -5 to 60 ℃, suitable for various working environments.
- Maximum Tensile Strength: For example, the maximum tensile strength of JAF100-27-150 is 28000 N ².
- Allowable Eccentricity and Swing Angle: Generally ± 5 °, with a certain installation error of 12.
- Dust Cover Material: Synthetic rubber, providing good sealing and dust-proof performance.
Technical Parameters:
| Attribute |
Value |
| Type |
Floating Joints |
| Series |
JAF |
| Product Type |
Simple |
| Specifications |
M16x1.5 Nominal Size |
| Cylinder Used |
Air Cylinder |
| Brand |
SMC® |
Applications:
Application Scenarios:
The product is designed to connect cylinders and hydraulic cylinders, perfect for scenarios where eccentricity and parallelism cannot be fully absorbed. It has found its usage mainly in the automation industry, connecting robotic arms, the handling of materials, assembly line automation, and precision positioning equipment.
If you are searching for a solution that offers high accuracy and reliability, the product will be your best bet. The state-of-the-art technology used to design and manufacture the product ensures that the connections are made securely and robustly, and that the product operates at optimum efficiency levels. Additionally, you can make customized orders based on your individual requirements.
In summary, whether you are a system integrator or an end-user in the automation and manufacturing industries, the product is a versatile, high-quality solution that will help you achieve efficient and dependable operations.
Packing and Shipping:
The SMC Solenoid Valves product packaging includes:
- Solenoid valve unit
- Installation manual
- Mounting bracket and screws
We take great care in packaging and shipping your SMC Solenoid Valves to ensure they arrive in excellent condition. Our standard shipping includes:
- Secure packaging to protect against damage during transit
- Tracking information to monitor delivery status
- Delivery to your specified address
