Product Description:
Design Features:
The JAF series floating joint is designed to absorb eccentricity and insufficient parallelism accuracy between the cylinder and the passive body. Unlike other joints, no axis alignment is needed and high-precision machining can be avoided.
With a flange type installation, it can be easily connected to cylinders with different diameters providing stable connection and convenient installation. The joint is suitable for cylinders and hydraulic cylinders, with pressure resistance up to 1MPa for cylinders and up to 3.5MPa for hydraulic cylinders. The sealing material made of resin offers excellent chemical and heat resistance.
The large swing angle and eccentricity of ± 5 °, with a certain installation error of 12 enables the JAF series floating joint to provide greater flexibility and adaptability.
Technical specifications:
The JAF series floating joint uses various connection diameters such as Rc1/4 or M27X1.5, suitable for different pipe diameter requirements. It can use compressed air and water to control various fluid needs with a pressure range of 0.05-1 MPa that suits various working pressures.
With an environmental temperature and fluid temperature range of -5 to 60℃, it is suitable for various working environments. The joint's maximum tensile strength is remarkable with, for example, the JAF100-27-150 having a maximum tensile strength of 28000 N ². The dust cover made of synthetic rubber provides good sealing and dust-proof performance.
Technical Parameters:
| Specifications |
M14x1.5 Nominal Size |
| Type 1 |
Floating Joints |
| Series |
JAF series with flange |
| Product Type |
Simple |
| Brand |
SMC® |
| Cylinder Used |
Air Cylinder |
Applications:
Application Scenarios:
This product is highly suitable for connecting cylinders and hydraulic cylinders, especially in situations where eccentricity and parallelism are insufficient to be absorbed. Its versatile design and features make it ideal for a variety of applications. Additionally, the product is highly functional and widely used in industries such as automated machinery, robotic arm connections, material handling systems, precision positioning equipment, and assembly line automation.
Its high durability and strength allow for optimal performance and long-lasting use, providing reliable and efficient results. It's an ideal solution for complex industrial problems, offering a reliable and effective way to connect and unite different parts of machinery and equipment.
The product's innovative design and ease of use make it an attractive alternative to traditional connection methods that require a certain level of skill, effort, and time. This makes it an excellent choice for businesses looking to improve their efficiency and productivity. Also, the product's versatility makes it easily adaptable to various applications, serving as an excellent tool for multiple industries and fields that require efficient and reliable machinery connections.
