Product Description:
Design Features:
- The JAF series floating joint can absorb eccentricity and insufficient parallelism accuracy between the cylinder and the passive body without axis alignment, which reduces the demand for high-precision machining.
- It adopts a flange type installation form, suitable for cylinders with different diameters, providing stable connection, and convenient installation.
- The floating joint has high pressure resistance performance and is suitable for cylinders and hydraulic cylinders with pressure up to 1 MPa and 3.5 MPa respectively.
- The main material used in the floating joint is resin which offers excellent chemical and heat resistance.
- The floating joint allows a large swing angle and a certain amount of eccentricity, providing greater flexibility and adaptability.
Technical specifications:
- The connection diameter is Rc1/4 or M27X1.5, and it is suitable for various pipe diameter requirements.
- The floating joint uses compressed air and water to meet various fluid control needs.
- The pressure range is 0.05-1 MPa and is suitable for various working pressures.
- The environmental temperature and fluid temperature range is -5 to 60 ℃ and it is suitable for various working environments.
- The maximum tensile strength of JAF100-27-150 is 28000 N ².
- The allowable eccentricity and swing angle is generally ± 5 °, with a certain installation error of 12.
- The dust cover material is synthetic rubber, which provides good sealing and dust-proof performance.
Technical Parameters:
| Brand: |
SMC® |
| Cylinder Used: |
Air Cylinder |
| Series: |
JAF |
| Type 1: |
Floating Joints |
| Product Type: |
Simple |
| Specifications: |
M12x 1.25 Nominal Size |
Looking for an SMC JAF series aluminum floating joint? The SMC aluminum floating joint with Floating Joints and Simple product type is perfect for you! It has a cylinder used of Air Cylinder and a specifications of M12x 1.25 Nominal Size.
Applications:
Application Scenarios
The product is designed for linking cylinders and hydraulic cylinders for various industrial applications. It is most suitable for scenarios where the eccentricity and parallelism of the cylinders are not adequate to be absorbed.
The product has found widespread use in automated machinery, robotic arms, material handling systems, and precision positioning equipment. It is also used extensively in assembly line automation.
The exceptional quality and versatility of the product make it ideal for use in industries where precision and accuracy are critical for efficient production processes. The flexible design of the product makes it highly adaptable to various industrial sectors and applications.
