SMC Corporation VH301-02 Manual Valve, 1/4 in. Port Size, Body Mount, Rc Thread, Manual Lever, VH Series

Product Description:

The SMC VH Series, including models VH301, VH300, VH312, VH311, VH332, VH330, and VH322, is a pneumatic hand rotary valve manually operated and specifically designed for industrial pneumatic systems. Renowned for its stable performance and versatile adaptability, this valve series is extensively utilized for circuit on-off control and directional management across various applications, such as automation machinery, machine tools, and pneumatic piping systems.

This range of hand rotary valves offers two thread connection sizes: 02 (1/4 inch) and 03 (3/8 inch). Additionally, derivative specifications like 02N and R are available to satisfy diverse pipeline installation needs. The valve body is constructed from die-cast aluminum alloy, providing excellent corrosion resistance due to surface oxidation treatment. It operates reliably within industrial environments ranging from -5℃ to 60℃. Equipped with a valve core that features a dual-seal structure—comprising both a hard seal and an elastic seal—this series ensures consistent sealing performance and meets SMC's industrial leakage standards. These valves are suitable for a working pressure range of 0 to 1.0 MPa, aligning well with standard pneumatic system requirements.

Structurally and operationally, the VH Series implements manual rotary operation as its fundamental mechanism, featuring precise gear positioning and a smooth rotary feel. This design effectively prevents misdirection caused by equipment vibrations. Most of the models utilize a two-position, three-way structure, while some can also function as two-position, two-way valves, enabling swift switching and shutdown within pneumatic circuits. Installation options include panel mounting and base mounting, with certain versions offering specialized mounting brackets to accommodate diverse equipment configurations.

Furthermore, these hand rotary valves are designed for oil-free lubrication, allowing long-term stable operation without the need for added lubricating oil, thereby significantly reducing maintenance expenses. Select models also feature an IP65 protection rating, enabling them to withstand challenging environments characterized by dust and humidity. When combined with accessories such as mufflers and pneumatic connectors, their range of application scenarios broadens considerably. Overall, the SMC VH Series represents a cost-effective and reliable choice for manual control components within the industrial pneumatic control sector.

Technical Parameters:

Applications:

The SMC two position three-way manual rotary valve is an essential component widely used in various industrial applications due to its reliable performance and user-friendly design. Manufactured by the reputable brand SMC, this valve series is CE certified, ensuring compliance with international quality and safety standards. Its robust construction and precise control capabilities make it ideal for pneumatic systems where accurate flow control is critical.

This pneumatic control manual rotary valve is designed to operate with dry compressed air as the working medium. It is crucial that oil and moisture are filtered out to avoid damage to the valve core, thereby enhancing the valve's longevity and operational efficiency. The valve operates effectively within a temperature range of -5℃ to 60℃, making it suitable for diverse environmental conditions encountered in industrial settings.

The SMC two position three-way manual rotary valve features a hand-operated mechanism, allowing for easy and precise manual control of pneumatic circuits. Its common port type, mostly two position three-way S, facilitates versatile applications such as switching air flow paths, controlling actuators, and managing pneumatic tools. These valves are widely used in industries like automation, manufacturing, packaging, and process control where manual intervention is necessary for system adjustments or maintenance.

With a minimum order quantity of just one piece and flexible packaging options including carton packaging as per client requirements, SMC ensures that customers receive products tailored to their needs. The supply ability of 5000 pieces per month guarantees steady availability to meet large-scale production demands. Additionally, the delivery time ranges from 1 to 7 workdays after payment, offering swift order fulfillment.

SMC provides convenient payment terms such as T/T, Western Union, and PayPal, facilitating smooth transactions for clients worldwide. The price of the SMC pneumatic rotary valve is negotiable, allowing potential buyers to discuss terms that best fit their budget and order size.

Overall, the SMC two position three-way manual rotary valve is an excellent choice for applications requiring dependable pneumatic control manual rotary valves. Its certified quality, operational efficiency, and customizable options make it a vital component in optimizing pneumatic system performance across various industrial occasions and scenarios.

Packing and Shipping:

All SMC Solenoid Valves are carefully packaged to ensure they arrive in perfect condition. Each valve is individually wrapped with protective materials and securely placed in a sturdy box to prevent any damage during transit.

For shipping, we use reliable carriers and provide tracking information so you can monitor your order every step of the way. Depending on your location and order size, various shipping options are available, including standard and expedited delivery.

We take great care in handling and shipping our products to guarantee timely delivery and customer satisfaction. For any special packaging or shipping requests, please contact our customer service team.
