Product Description:
The SMC VH Series pneumatic hand rotary valves, including models VH301, VH300, VH312, VH311, VH332, VH330, and VH322, are manually operated directional control components specifically designed for industrial pneumatic systems. Known for their reliable performance and versatile adaptability, these valves are extensively utilized in applications such as automation equipment, machine tools, and pneumatic pipelines for circuit on-off and directional control purposes.
This series offers two thread connection sizes: 02 (1/4 inch) and 03 (3/8 inch). Additionally, derivative variants like 02N and R are available to accommodate various pipeline installation requirements. The valve bodies are constructed from die-cast aluminum alloy, which undergoes surface oxidation treatment to provide excellent corrosion resistance. These valves are built to withstand industrial environments with temperature ranges from -5℃ to 60℃. Inside, the valve core integrates a dual sealing design combining hard and elastic seals, ensuring stable sealing performance and a leakage rate that meets SMC’s industrial standards. They operate effectively within a working pressure range of 0 to 1.0 MPa, making them suitable for conventional pneumatic systems.
Structurally, the VH Series hand rotary valves operate through manual rotary action, featuring precise gear positioning and a smooth turning feel, which helps prevent incorrect valve direction caused by vibrations. Most variants employ a two-position three-way configuration, while some models support a two-position two-way function, enabling rapid switching and shutoff of pneumatic circuits. Installation versatility is provided through two mounting options: panel mounting and base mounting. Certain models also include specialized mounting brackets, allowing compatibility with a diverse range of equipment layouts.
Furthermore, these hand rotary valves are designed with oil-free lubrication, allowing long-term stable operation without the need for additional lubricants, thus significantly reducing maintenance requirements. Some models achieve an IP65 protection rating, granting resistance against dust and moisture, which suits demanding working conditions. When combined with accessories such as mufflers and pneumatic connectors, the application possibilities expand even further. Overall, the SMC VH Series represents a cost-effective and reliable choice for manual control components within the industrial pneumatic control sector.
Technical Parameters:
| Series |
SMC Pneumatic Rotary Valve |
| Working Pressure Range |
0~1.0 MPa |
| Port Type |
Mostly Two Position Three-way S |
| Working Medium |
Dry Compressed Air, Oil And Moisture Need To Be Filtered Out To Avoid Valve Core Damage |
| Working Temperature Range |
-5℃~60℃ |
| Type |
Hand-operated Valve |
| VH200-02 (1/4) sealed type |
| VH201-02 (1/4) Medium Drain Type |
| VH02-02 (1/4) 2-position type |
| VH400-04 (1/2) sealed type |
| VH402-04 (1/2) 2-position formula |
| VH210-02 (1/4) sealed type |
| VH212-02 (1/4) 2-position type |
| VH211-02 (1/4) Medium Drain Type |
| VH410-04 (1/2) sealed type |
| VH412-04 (1/2) 2-position formula |
| VH250-02 (1/4) sealed type |
| VH251-02 (1/4) Medium Drain Type |
| VH252-02 (1/4) 2-position type |
| VH400-N04 (1/2) sealed type |
| VH242-02 (1/4) 2-position type |
| VH240-02 (1/4) sealed type |
| VH241-02 (1/4) Medium Drain Type |
| VH400-06 (3/4) sealed type |
| VH200-N02-R (1/4) sealed type |
| VH200-F02 (1/4) sealed type |
| VH220-02 (1/4) bottom 4 holes sealed type |
| VH230-02 (1/4) bottom 4 holes sealed type |
| VH221-02 (1/4) bottom 4 holes leak type |
| VH231-02 (1/4) bottom 4 holes leak type |
| VH222-02 (1/4) bottom 4 holes 2-position type |
| VH232-02 (1/4) bottom 4 holes 2-position type |
| VH401-04 (1/2) sealed type |
| VH400-02 uses a patch core transformer (1/4) with a sealed design |
| VH400-03 Core Replacement Transformer (3/8) with Sealed Type |
Applications:
The SMC two position three-way manual rotary valve, part of the VH series manual rotary valve lineup, is a versatile and reliable solution designed for a wide range of industrial applications. Known for its robust construction and precise operation, the SMC manual rotary valve is widely used in pneumatic control systems where manual intervention is necessary. This valve is ideal for controlling the direction of dry compressed air within a pressure range of 0 to 1.0 MPa, making it suitable for various automation and process control scenarios.
One of the primary application occasions for the SMC VH series manual rotary valve is in manufacturing plants that require precise manual control over pneumatic systems. It is commonly utilized in assembly lines, packaging machines, and other automated equipment where quick switching between air supply paths is essential. The valve's ability to operate within a temperature range of -5℃ to 60℃ ensures reliable performance even in moderately harsh environments.
Given its hand-operated design, the SMC manual rotary valve is also well-suited for maintenance and testing scenarios. Technicians often use it to manually isolate sections of pneumatic circuits, allowing for safe and efficient troubleshooting without shutting down entire systems. Its CE certification guarantees compliance with European safety and quality standards, providing assurance for users in various regions.
In addition to industrial automation, the SMC two position three-way manual rotary valve finds applications in laboratory settings, air treatment systems, and custom pneumatic assemblies. The valve’s compatibility with dry compressed air, with oil and moisture filtered out to protect the valve core, makes it a dependable choice for sensitive equipment. Its packaging options, including cartons or customized packaging as per client requirements, ensure safe delivery and easy integration into existing systems.
With a minimum order quantity of just one piece and a supply ability of 5000 pieces per month, the SMC manual rotary valve is accessible for both small-scale projects and large industrial deployments. The delivery time ranges from 1 to 7 working days after payment, with flexible payment terms including T/T, Western Union, and PayPal. Pricing is negotiable, allowing customers to find the best terms for their procurement needs.
Overall, the SMC VH series manual rotary valve is an essential component for any application requiring reliable manual control of pneumatic flows. Its durability, ease of operation, and compliance with international standards make it a preferred choice across diverse industries worldwide.
