Product Description:
The SMC VH Series hand rotary valves (models VH301, VH300, VH312, VH311, VH332, VH330, and VH322) are pneumatic directional control components operated manually. These valves are specifically designed for industrial pneumatic systems, offering stable performance and excellent adaptability. They are commonly employed for on-off switching and directional control within various applications, including automation machinery, machine tools, and pneumatic pipeline systems.
This series includes valves with two thread connection sizes: 1/4 inch (type 02) and 3/8 inch (type 03). Additionally, derivative variants such as 02N and R are available to accommodate diverse pipeline installation requirements. The valve bodies are constructed from die-cast aluminum alloy, which undergoes surface oxidation treatment to provide strong corrosion resistance. These valves operate reliably within an industrial temperature range of -5°C to 60°C. Inside, the valve cores feature a dual sealing structure combining hard and elastic seals, ensuring stable sealing performance with leakage rates that meet SMC’s industrial standards. They are suitable for working pressures ranging from 0 to 1.0 MPa, aligning well with typical pneumatic system conditions.
Structurally and operationally, the VH Series utilizes manual rotary operation as its fundamental mode. The valves incorporate clear gear positioning and offer a smooth rotary experience by hand, which helps prevent accidental misdirection triggered by equipment vibrations. Most models have a two-position, three-way configuration, with some adapted for two-position, two-way functionality to enable rapid switching and shutdown of pneumatic circuits. Installation is versatile, supporting both panel and base mounting options. Certain models come with specialized mounting brackets to suit various equipment layouts and configurations.
Moreover, these hand rotary valves feature oil-free lubrication, enabling long-term stable operation without the need for additional lubricants. This significantly cuts down on maintenance expenses. Some valves are rated with an IP65 protection level, allowing them to withstand challenging environments with dust and moisture exposure. When used alongside accessories such as mufflers and pneumatic connectors, the range of possible application scenarios is broadened. Overall, the SMC VH Series provides a cost-effective manual control solution within the industrial pneumatic control field.
Technical Parameters:
| Working Pressure Range |
0~1.0MPa |
| Working Medium |
Dry Compressed Air, Oil And Moisture Need To Be Filtered Out To Avoid Valve Core Damage |
| Working Temperature Range |
-5℃~60℃ |
| Series |
SMC Pneumatic Rotary Valve |
| Type |
Hand-operated Valve |
| Port Type |
Mostly Two Position Three-way S |
Applications:
The SMC solenoid valves, including the highly reliable SMC manual rotary valve and the VH series manual rotary valve, are widely utilized across various industrial and commercial applications. These valves are designed to offer precise control of fluid flow, making them ideal for automated systems where accurate and timely actuation is critical. Their versatility allows them to be used in pneumatic systems, manufacturing automation, packaging machinery, and process control industries.
One of the key application occasions for the SMC solenoid valves is in pneumatic equipment, where controlling compressed air is essential. The valves operate efficiently within a working temperature range of -5℃ to 60℃ and a working pressure range of 0 to 1.0 MPa, making them suitable for environments with moderate temperature fluctuations and pressure demands. The valves are specifically designed to work with dry compressed air, and it is important that oil and moisture are filtered out to avoid damage to the valve core, ensuring longevity and reliable performance.
In industrial automation, the SMC manual rotary valve and VH series manual rotary valve serve as crucial components for controlling air flow in conveyor systems, robotic arms, and other automated machinery. Their hand-operated functionality provides manual override options, which is essential during maintenance or emergency situations. The two-position three-way port type design enhances their usability in various circuit configurations, allowing for flexible integration into existing systems.
SMC solenoid valves are also certified with CE, ensuring they meet stringent European safety and quality standards. This certification makes them suitable for use in industries that demand high compliance, such as pharmaceuticals, food processing, and automotive manufacturing. The valves are packaged carefully in cartons or as per client requirements, ensuring safe delivery.
With a minimum order quantity of just one piece and a supply ability of 5000 pieces per month, SMC offers flexible procurement options. Pricing is negotiable, and the delivery time ranges from 1 to 7 work days after payment, making the valves accessible for both small and large-scale projects. Payment can be conveniently made via T/T, Western Union, or PayPal, providing additional ease for international customers.
Overall, the SMC manual rotary valve and VH series manual rotary valve are trusted solutions for reliable, efficient, and precise fluid control across a wide array of applications and scenarios, supported by excellent supply capabilities and customer-centric service terms.
Packing and Shipping:
Each SMC solenoid valve is carefully packaged to ensure protection during transit. The valve is first sealed in an anti-static bag to prevent any damage from electrostatic discharge. It is then placed in a custom-fitted foam insert within a sturdy cardboard box to minimize movement and impact.
The packaging materials are designed to be environmentally friendly and recyclable. All boxes are clearly labeled with the product model number, specifications, and handling instructions to facilitate easy identification and safe handling.
For shipping, SMC solenoid valves are dispatched through reliable carriers with tracking options available. Depending on the destination, we offer standard and expedited shipping services to meet customer needs. Special care is taken to comply with international shipping regulations, ensuring timely and secure delivery worldwide.
