Product Description:
The SMC VH Series, which includes models VH301, VH300, VH312, VH311, VH332, VH330, and VH322, is a pneumatic hand rotary valve designed for manual directional control in industrial pneumatic systems. Known for its stable performance and versatile adaptability, this valve series is extensively utilized for circuit on-off functions and directional control across various applications such as automation machinery, machine tools, and pneumatic pipelines.
This series offers two thread connection sizes: 02 (1/4 inch) and 03 (3/8 inch). Additionally, derivative versions like 02N and R are available to accommodate different pipeline installation needs. The valve body is crafted from die-cast aluminum alloy and undergoes surface oxidation treatment to ensure excellent corrosion resistance. It performs reliably within industrial temperature ranges from -5℃ to 60℃. The valve core features a dual-seal structure combining hard and elastic seals, delivering stable sealing efficiency and leakage rates that comply with SMC’s industrial standards. It is suitable for a working pressure range of 0 to 1.0 MPa, making it compatible with standard pneumatic system requirements.
Structurally and operationally, the VH Series hand rotary valve utilizes manual rotary action with precise gear positioning and a smooth turning feel. This design helps prevent misoperation caused by vibrations in the equipment. Most models incorporate a two-position three-way configuration, while some are also compatible with two-position two-way functionality. This enables quick switching and shutdown of pneumatic circuits. Installation can be carried out using either panel mounting or base mounting methods, and select models come equipped with specialized mounting brackets to suit diverse equipment layouts.
Moreover, the VH Series features oil-free lubrication, allowing for long-term stable operation without the need for additional lubricants, which significantly reduces maintenance efforts and costs. Certain models boast an IP65 protection rating, providing resistance against dust and moisture, thereby ensuring dependable performance even under harsh conditions. When combined with accessories such as mufflers and pneumatic connectors, the range of potential applications widens. Overall, the SMC VH Series offers a cost-effective solution for manual pneumatic control within industrial environments.
Technical Parameters:
| Working Temperature Range |
-5℃~60℃ |
| Series |
SMC Pneumatic Rotary Valve |
| Type |
Hand-operated Valve |
| Port Type |
Mostly Two Position Three-way S |
| Working Medium |
Dry Compressed Air, Oil And Moisture Need To Be Filtered Out To Avoid Valve Core Damage |
| Working Pressure Range |
0~1.0MPa |
| VH301-02 vent type (1/4) hole on the side |
| VH301-03 vent type (3/8) hole on the side |
| VH311-02 vent type (1/4) hole on the side |
| VH311-03 vent type (3/8) hole on the side |
| VH320-02 sealed (1/4) with 4 holes at the bottom |
| VH320-03 medium sealed (3/8) 4 hole bottom |
| VH330-02 sealed (1/4) with 4 holes at the bottom |
| VH330-03 medium sealed (3/8) 4 hole bottom |
| VH332-02 sealed (1/4) with 4 holes at the bottom |
| VH332-03 medium sealed (3/8) 4 hole bottom |
| VH322-02 2-position (1/4) 4 hole bottom |
| VH322-03 2-position (3/8) 4 hole bottom |
| VH300-N02-R with sealed (1/4) hole on the side |
| VH300-02-L with sealed (1/4) hole on the side |
| VH300-03-L medium sealed (3/8) hole on the side |
| VH312-03 two position (3/8) hole on the side |
| VH312-02 two position (1/4) hole on the side |
| VH300-02 with sealed (1/4) hole on the side |
| VH300-03 sealed (3/8) hole on the side |
| VH302-02 two position (1/4) hole on the side |
| VH302-03 two position (3/8) hole on the side |
| VH310-02 with sealed (1/4) hole on the side |
| VH310-03 sealed (3/8) hole on the side |
| VH312-F02 two position (1/4) hole on the side |
| VH321-02 Medium Drain (1/4) 4 hole bottom |
| VH321-03 Medium Drain (3/8) 4 hole bottom |
| VH331-02 Medium Drain (1/4) 4 hole bottom |
| VH331-03 Medium Drain (3/8) 4 hole bottom |
| VH310-F03 sealed (3/8) hole on the side |
| VH300-N02 with sealed (1/4) hole on the side |
| VH311-F03 vent type (3/8) hole on the side |
| VH300-04 with sealed (1/2) hole on the side |
| VH300-03-R with sealed (3/8) hole on the side |
| VH310-N03 sealed (3/8) hole on the side |
Applications:
The SMC two position three-way manual rotary valve is widely utilized in various industrial and automation applications due to its reliable performance and versatile functionality. As part of the SMC Pneumatic Rotary Valve series, this valve is designed to control the flow of dry compressed air efficiently, making it an essential component in pneumatic systems where precision and durability are paramount. Its capability to filter out oil and moisture ensures optimal operation and longevity, which is crucial in maintaining system integrity.
This SMC manual rotary valve is particularly suitable for scenarios requiring manual control over air flow, such as in assembly lines, packaging machinery, and automated manufacturing processes. The hand-operated valve design allows operators to easily switch positions, enabling quick adjustments and control in real-time, which is invaluable in dynamic production environments. Its working temperature range of -5℃ to 60℃ makes it adaptable to various climate conditions, further broadening its application scope.
In addition to industrial automation, the SMC two position three-way manual rotary valve finds applications in laboratory equipment, testing devices, and pneumatic tools where precise air flow control is necessary. The CE certification assures users of the product’s compliance with European safety and quality standards, ensuring reliability and safety in all application scenarios.
SMC offers a minimum order quantity of just one piece, making it accessible for both small-scale projects and large industrial deployments. With a supply ability of 5000 pieces per month and a delivery time of 1-7 work days after payment, customers benefit from efficient procurement and timely delivery. Packaging is flexible and can be tailored to client requirements, typically shipped in cartons to ensure product safety during transit.
Pricing for the SMC two position three-way manual rotary valve is negotiable, accommodating various budgetary needs. Payment terms include T/T, Western Union, and PayPal, providing convenient options for international buyers. The robust construction, precise functionality, and versatile application occasions make the SMC manual rotary valve an indispensable component in modern pneumatic and automation systems.
