IP65 Protection Class SMC Solenoid Valves Fast Response Time ITY1050-311S2

Product Description:

The ITV1000 series is a compact electro-pneumatic proportional pressure regulator manufactured by SMC. It is designed to continuously and accurately adjust the output pressure of compressed air through an analog voltage or current signal received from a PLC. This is achieved using a closed-loop control design, ensuring precise pressure regulation at all times.

This product range includes two main pressure categories: the ITV1030, which covers a pressure range from 0.005 to 0.5 MPa, and the ITV1050, with a range from 0.005 to 0.9 MPa. The series also offers various variants identified by suffix codes such as 011, 012, 013, 112, 113, 211, 212, 213, 312, and 313. Each suffix corresponds to different signal configurations to suit diverse application needs.

The ITV1000 series utilizes a high-precision closed-loop sensor structure. It boasts excellent performance characteristics including linearity within ±1% of full scale (FS), hysteresis less than or equal to 0.5% FS, sensitivity of 0.2% FS, and repeatability of ±0.5% FS. Additionally, it offers a fast no-load response time of 0.1 seconds, which ensures stable pressure regulation and effective resistance to interference.

Its compact and lightweight design supports DIN rail mounting for easy installation. The regulator is equipped with a built-in LED digital pressure indicator and a fault alarm LED for real-time monitoring. With an IP65 rating, it provides excellent protection against dust and water ingress, making it suitable for use with clean, dry compressed air environments.

Technical Parameters:

Applications:

The SMC Electro-pneumatic Proportional Regulator, model ITV1030, is a highly reliable and efficient proportional valve designed for precise air pressure control in various industrial applications. Certified with CE standards, this electronically controlled air regulator offers excellent performance with a hysteresis of ≤0.5%FS, ensuring minimal deviation and high accuracy in pressure regulation within the range of 0.005 to 0.5 MPa. Its IP65 protection class guarantees durability and resistance against dust and water, making it suitable for demanding environments.

This proportional valve is widely used in automation systems where precise control of pneumatic pressure is essential. Common application occasions include manufacturing lines, robotics, and packaging machinery, where stable and responsive pressure control directly impacts product quality and process efficiency. The rapid response time of 0.1 seconds (no-load) allows for dynamic adjustments, making the ITV1030 ideal for applications requiring quick and accurate pressure modulation.

In addition to industrial automation, the SMC ITV1030 proportional valve finds application in the automotive industry for controlling air suspensions and braking systems that demand precise pressure control. It is also utilized in laboratory equipment and testing devices where accurate pressure regulation is critical to experimental consistency and safety.

The product is designed for easy integration and flexibility, with packaging options customizable as per client requirements, and a supply ability of 5000 pieces per month. Customers benefit from a minimum order quantity of just 1 piece, with pricing available through negotiation. The delivery time ranges from 1 to 7 workdays after payment, and multiple payment terms including T/T, Western Union, and PayPal are accepted, facilitating smooth procurement processes.

Overall, the SMC ITV1030 proportional valve stands out as an advanced electronically controlled air regulator, suitable for a broad spectrum of scenarios demanding precise and reliable air pressure control. Its combination of fast response, high accuracy, robust protection, and flexible supply terms makes it a preferred choice for industries aiming to enhance automation and control efficiency.

Packing and Shipping:

All SMC Solenoid Valves are carefully packaged to ensure safe delivery and optimal protection during transit. Each valve is individually wrapped and secured in a sturdy box with cushioning materials to prevent damage.

The packaging includes clear labeling with product specifications, model numbers, and handling instructions to facilitate easy identification and proper handling.

For shipping, we use reliable carriers with tracking options to guarantee timely and secure delivery. Special care is taken for international shipments to comply with customs regulations and ensure smooth clearance.

We also offer customized packaging solutions upon request to meet specific requirements or branding needs.
