Product Description:
The Burkert 6281 series belongs to the S.EV series and is a servo-assisted 2/2-way diaphragm solenoid valve. It is engineered to provide reliable shut-off, precise dosing, and efficient filling of neutral gaseous and liquid media. Constructed with a stainless steel body combined with an EPDM (ethylene-propylene-diene rubber) seal, this valve delivers outstanding corrosion resistance as well as excellent flexibility at low temperatures, making it suitable for demanding industrial environments.
For proper operation, the valve requires a minimum differential pressure. Its vibration-resistant coil system, secured centrally with screws, alongside a damped design, ensures quiet closing and enhances the valve's durability. The standard brass housing meets all European drinking water standards (KTW/W270), while a dezincification-resistant brass variant is offered to meet the requirements of other markets. Additionally, a stainless steel version is available for further versatility.
To optimize power consumption, the valve can be equipped with coils featuring "Kick and Drop" (KD) electronic assemblies, which utilize double coil technology. Maintenance and commissioning are simplified with the option of a manual override. When used with an appropriate cable plug conforming to DIN EN 175301-803 Form A, the valves achieve an IP65 protection rating. Moreover, combining the valve with a stainless steel housing elevates the protection class to NEMA 4X.
Installation flexibility is another advantage of the Burkert 6281 series, as the valve can be mounted in any orientation, though it is recommended to position the actuator upright for optimal performance.
Features:
Stainless Steel Body Construction
The body is crafted from stainless steel, delivering outstanding corrosion resistance. This makes it ideal for use with aggressive media and in demanding environmental conditions.
EPDM Seal
The seal is made from EPDM (Ethylene-Propylene-Diene Rubber), which offers excellent durability against water, dilute acids, alkalis, and various other substances. It can withstand media temperatures ranging from -30°C up to +90°C, and even up to +100°C when combined with an epoxy coil.
Servo-Assisted Diaphragm Design
This design ensures dependable operation for functions such as shut-off, dosing, and filling when handling neutral or mildly aggressive fluids.
Normally Closed Configuration
The circuit functions in a normally closed (NC) mode, providing fail-safe operation suitable for precise process control requirements.
Wide Port and Orifice Range
Available port sizes range from G1/4 to G2, with orifice sizes spanning from 10 mm to 40 mm. This wide range accommodates various flow demands.
Wide Pressure Range
The device operates efficiently across a broad pressure range, from 0.2 bar up to 16 bar, providing versatility in different applications.
Standard 8W Coils
Equipped with 8W coils that support a 100% continuous duty cycle, ensuring reliable and long-lasting operation.
Multiple Voltage Options
It is compatible with multiple voltage standards, including DC 24V, AC 24V, and AC 220V, with a tolerance of ±10% for worldwide use.
IP65 / NEMA 4X Protection
The device features an IP65 / NEMA 4X rating, making it dust-tight and resistant to water jets when paired with a suitable cable plug.
Vibration-Proof Coil System
A centrally screwed coil system ensures secure functioning even in harsh industrial environments subject to vibration.
Damped Design for Quiet Closing
The design incorporates damping mechanisms that reduce noise during closing, making it suitable for noise-sensitive environments.
Energy-Saving Option
The Kick-and-Drop (KD) double coil technology helps lower power consumption throughout the operation, enhancing energy efficiency.
Manual Override Option
A manual override feature is available, facilitating ease of maintenance and commissioning activities.
Drinking Water Approvals
The standard brass housing complies with all European standards for drinking water applications, ensuring safety and reliability.
Explosion-Proof Variants
Versions certified to ATEX standards are offered for use in hazardous areas where explosion protection is critical.
Flexible Installation
The device supports installation in any position, though upright installation of the actuator is recommended for optimal performance.
Technical Parameters:
| Valve Type |
2/2-way Diaphragm Solenoid Valve |
| Power Consumption |
8W |
| Body Material |
Stainless Steel |
| Voltage Options |
DC24V, AC24V, AC220V |
| Seal and Diaphragm Material |
EPDM |
| Orifice Sizes |
10 mm, 13 mm, 20 mm, 25 mm, 40 mm |
| Circuit Function |
Normally Closed |
| Medium Temperature |
-30°C to +90°C |
| Pressure Range |
0.2 to 16 Bar |
| Port Sizes |
G1/4, G3/8, G1/2, G3/4, G1, G1 1/4, G1 1/2, G2 |
Applications:
Water Treatment
Effective management of water is essential in treatment plants and drinking water distribution systems. This ensures safe and clean water supply through precise control mechanisms.
Compressed Air Systems
Ensuring dependable regulation of compressed air is critical in industrial automation and machinery operations. Reliable control solutions enhance efficiency and performance in these systems.
Shut-Off, Dosing, and Filling
Industrial processes often require accurate control of neutral gaseous and liquid media. Applications include shut-off functions, dosing of substances, and filling operations to maintain process integrity.
Heating and Refrigeration
Fluid regulation plays a pivotal role in heating and cooling systems. Proper fluid control optimizes the performance of both heating and refrigeration units.
Industrial Automation
In manufacturing and process automation, versatile fluid control solutions are employed to support a wide range of general-purpose applications, enhancing automation capabilities.
Pneumatic Control Systems
Precise control of pneumatic actuators and cylinders is vital for efficient pneumatic systems. These controls enable smooth and reliable operation in various mechanical applications.
Process Control
Control systems designed for chemical, pharmaceutical, and other general process industries ensure accurate monitoring and regulation to maintain quality and safety standards.
Cooling and Air Conditioning
Managing cooling water and chilled water circuits is essential for effective climate control. These systems rely on advanced fluid control technologies to maintain desired temperatures.
Hazardous Areas
For environments with explosive atmospheres, ATEX certified versions of control devices are available, ensuring safety and compliance with strict regulations.
Support and Services:
Burkert provides comprehensive Product Technical Support and Services for its Solenoid Valve range to ensure optimal performance and customer satisfaction. Our support includes detailed product information, installation guidance, troubleshooting assistance, and maintenance recommendations. Customers can access technical datasheets, operation manuals, and CAD drawings to facilitate proper application and integration of the solenoid valves.
Our experienced technical team is available to assist with product selection, system design advice, and customization options to meet specific process requirements. We also offer training sessions and webinars to help users understand the functionality and best practices for Burkert solenoid valves.
Burkert’s after-sales service includes warranty support, repair services, and spare parts supply to maximize the lifecycle and reliability of the solenoid valves. We are committed to delivering high-quality solutions and responsive support to help customers achieve efficient and trouble-free operation in their fluid control systems.
Packing and Shipping:
The Burkert Solenoid Valve is carefully packaged to ensure maximum protection during transit. Each valve is individually packed in a sturdy, custom-designed box with protective foam inserts to prevent damage from shocks and vibrations.
All packaging materials are selected to provide durability and resistance to moisture and dust, maintaining the product’s integrity until it reaches the customer.
Shipping options include standard, expedited, and express delivery services, with tracking available for all shipments. The product is shipped via trusted carriers to ensure timely and secure delivery worldwide.
Each package is clearly labeled with product information, handling instructions, and safety warnings to facilitate proper handling during shipping and storage.
Bulk orders are palletized and shrink-wrapped to optimize loading efficiency and protect multiple units during transport.
