Product Description:
The 6281 series is a servo-assisted 2/2-way diaphragm solenoid valve engineered for dependable shut-off, dosing, and filling of neutral and mildly aggressive gaseous and liquid media. Constructed with a stainless steel body combined with an FKM (fluororubber) seal, this valve provides outstanding corrosion resistance and high-temperature capability, making it ideal for challenging industrial environments.
For proper operation, the valve requires a minimum differential pressure. Its vibration-resistant, centrally screwed coil system along with a damped design ensures quiet closing and enhances the valve’s longevity. The FKM diaphragm exhibits excellent resistance against hot air, chemical solutions, oils, and solvents, supporting media temperatures ranging from 0°C up to +120°C when used with an epoxy coil. The stainless steel body adds further robustness, suitable for handling aggressive media in tough conditions.
To optimize power consumption during operation, specialized coils featuring electronic power reduction — known as Kick and Drop double coil technology — are available. Additionally, the valve can be equipped with a manual override feature, facilitating easy maintenance and commissioning. When combined with an appropriate cable plug that complies with DIN EN 175301-803 Form A, the valves achieve an IP65 protection rating. If outfitted with a stainless steel housing, they meet the NEMA 4X standard. Installation is flexible, allowing the valve to be mounted in any orientation, though positioning the actuator upright is preferable.
Features:
The product features a robust stainless steel body construction, which ensures outstanding resistance to corrosion. This makes it highly suitable for use with aggressive media and in demanding environmental conditions.
It utilizes FKM (fluororubber) seal material, known for its excellent durability against hot air, various chemical solutions, oils, and solvents. The seal can withstand media temperatures ranging from 0°C up to +120°C.
The servo-assisted diaphragm design guarantees dependable performance in applications such as shut-off, dosing, and filling of neutral or mildly aggressive media, enhancing overall operational reliability.
Configured as normally open (Circuit function B), the device provides fail-open functionality when de-energized, ensuring safety and system integrity during power interruptions.
A wide range of port and orifice sizes is available, with ports ranging from G1/4 to G1 1/2 and orifice sizes between 10 mm and 40 mm. This versatility allows the device to meet diverse flow requirements effectively.
The product operates efficiently across a broad pressure spectrum, from as low as 0.2 bar up to 16 bar, accommodating various process demands with ease.
Equipped with standard 8W coils, it supports a 100% continuous duty cycle, ensuring reliable and long-lasting operation without interruption.
Multiple voltage options are provided for global compatibility, including DC 24V, AC 24V, and AC 220V, all with a tolerance of ±10% to suit different electrical standards.
With IP65 / NEMA 4X protection, the product is dust-tight and safeguarded against water jets when used with an appropriate cable plug, making it suitable for various harsh environments.
The vibration-proof coil system, secured with a central screw, ensures stable and secure operation even in challenging industrial settings.
A damped design contributes to quiet closing action, which is particularly beneficial for installation in noise-sensitive environments.
For energy efficiency, an optional Kick-and-Drop (KD) double coil technology is available that reduces power consumption during operation, helping to lower operational costs.
Maintenance is simplified with an optional manual override feature, allowing easy servicing and commissioning without the need for specialized tools.
Explosion-proof variants certified to ATEX standards are also available, enabling safe use in hazardous area applications.
The product offers flexible installation options, capable of being mounted in any orientation, with a preference for the actuator to be positioned upright.
Its response time ranges from 0.1 to 4 seconds depending on the orifice size and differential pressure, ensuring timely and precise operation.
Technical Parameters:
| Protection Class |
IP65 |
| Body Material |
Stainless Steel |
| Seal and Diaphragm Material |
FKM |
| Valve Type |
2/2-way |
| Orifice Sizes |
10 Mm, 13 Mm, 20 Mm, 25 Mm, 40 Mm |
| Voltage Options |
DC24V, AC24V, AC220V |
| Circuit Function |
Normally Open |
| Port Sizes |
G1/4, G3/8, G1/2, G3/4, G1, G1 1/4, G1 1/2, G2 |
Applications:
Chemical processing requires reliable control systems capable of handling aggressive chemicals, solvents, and corrosive substances. Ensuring safety and efficiency in these environments is critical for maintaining operational integrity.
Hot air and gas systems involve the management and control of hot air and various gaseous media, with temperatures reaching up to +120°C. These systems are designed to maintain stable and accurate control under high-temperature conditions.
When it comes to oil and solvent handling, specialized solutions are necessary to accommodate oils, solvents, and other hydrocarbon-based fluids. These applications demand equipment that can safely and effectively manage such fluids without degradation or risk.
Industrial automation focuses on general-purpose fluid control within manufacturing and process automation environments. This broad category includes numerous applications where precise fluid regulation improves productivity and process reliability.
Water treatment processes require dependable control mechanisms for managing water in treatment plants and various industrial water systems. Proper fluid control ensures efficient treatment and adherence to environmental standards.
Process control covers a wide range of industries, including chemical and pharmaceutical sectors, requiring precise management of complex processes. Effective process control facilitates quality assurance and optimized operational performance.
Applications involving shut-off, dosing, and filling demand versatile control of both neutral and aggressive gaseous and liquid media. These operations are essential in manufacturing and packaging processes where accuracy and safety are paramount.
For hazardous areas, ATEX certified versions of control equipment are available, ensuring safe operation within explosive environments. This certification guarantees compliance with strict safety standards in potentially dangerous settings.
Customization:
Introducing the BURKERT Solenoid Valve, model number 00322547 SS, a high-quality Burkert Electromagnetic Valve designed and manufactured in CHINA. This 2/2-way valve features a Normally Open circuit function and is protected with an IP65 protection class, ensuring reliable performance in various applications.
The valve offers multiple voltage options including DC24V, AC24V, and AC220V to suit different operational requirements. It uses FKM material for the seal and diaphragm, providing excellent durability and chemical resistance.
Certified with CE, the Burkert Electromagnetic Valve guarantees compliance with international quality standards. We provide flexible customization services with a minimum order quantity of just 1 piece, making it ideal for both small and large scale needs.
Packaging is done carefully in cartons or as per clients' specific requirements to ensure safe delivery. Our supply ability is 5000 pieces per month, with a delivery time of 1-7 work days after payment confirmation.
Payment terms are convenient and secure, including T/T, Western Union, and PayPal options. Pricing is negotiable to accommodate various budget considerations.
Choose the BURKERT Solenoid Valve for dependable performance, efficient operation, and customization options tailored to your needs.
Packing and Shipping:
The Burkert Solenoid Valve is carefully packaged to ensure safe delivery and optimal protection during transit. Each valve is securely placed in a custom-fitted foam insert within a sturdy cardboard box to prevent movement and damage.
All packaging materials are selected to be durable and environmentally friendly, providing cushioning against shocks and vibrations. The product is also sealed in a protective plastic wrap to guard against moisture and dust.
For shipping, Burkert uses reliable carriers with tracking options to guarantee timely and secure delivery. Each shipment is accompanied by detailed documentation including the product datasheet, installation instructions, and warranty information.
Special care is taken for international shipments to comply with customs regulations and to ensure the solenoid valves arrive in perfect working condition.
