Product Description:
The IMI Norgren VCB22 Series represents a high-performance solenoid actuated spool valve, designed to deliver versatile directional control functions including 3/2, 5/2, and 5/3 configurations. This series is tailored to meet a broad spectrum of industrial pneumatic automation needs, ensuring reliable and efficient operation across various applications.
Constructed with a compact aluminum housing, the VCB22 valves come equipped with standard LED indicator lights for easy status monitoring. They feature an internal pilot air supply and support flow rates ranging from 245 to 3350 liters per minute. This makes them suitable for pneumatic circuits that vary from miniature setups to demanding high-flow requirements.
The series is available in four different valve widths—18mm, 22mm, 27mm, and 34mm—with port size options including M5, G1/8, G1/4, G3/8, and G1/2. Additionally, NAMUR mounting options are offered to enhance installation flexibility. The VCB22 also incorporates a sub-base system that facilitates straightforward manifold assembly and simplifies maintenance tasks.
Due to their robust design and adaptable features, valves from the VCB22 series are commonly employed in various industries such as packaging machinery, automotive production, food and beverage processing, textile manufacturing, chemical processing, and general industrial automation. Their versatility and performance make them a dependable choice for a wide array of applications.
Features:
Introducing the authentic IMI Norgren industrial solenoid valves, renowned for their trusted brand quality and dependable performance. These valves come in multiple directional control configurations, including 3/2, 5/2, and 5/3 types, catering to various application needs.
Customers can choose from four different valve widths to best suit their system requirements: 18mm (Type A), 22mm (Type B), 27mm (Type C), and 34mm (Type D). Additionally, a wide range of port options is available to enhance compatibility, featuring sizes such as M5, G1/8, G1/4, G3/8, G1/2, along with NAMUR standards G1/4 and G3/8.
These solenoid valves offer a high flow capacity ranging from 245 to 3350 liters per minute at 6 bar inlet pressure with a 1 bar pressure drop, ensuring efficient fluid control. An LED indicator light is included as a standard feature, providing clear and immediate feedback on the valve’s power status.
For added convenience during commissioning and maintenance, the valves incorporate a push and turn manual override lock. Designed for continuous industrial operation, they boast a 100% duty rating and an IP65 protection class, making them well-suited for harsh environmental conditions.
Constructed with a lightweight yet durable aluminum housing and equipped with NBR seals optimized for compressed air applications, these valves ensure longevity and reliable sealing performance. The sub-base mounting system simplifies piping configurations and supports easy manifold assembly.
These units require an internal pilot air supply, eliminating the need for any external pilot systems. Their voltage tolerance of ±10% ensures stable operation despite fluctuations in industrial power supply.
Available in both single solenoid (spring return) and double solenoid versions, the valves provide flexibility to suit different control needs. For the 5/3 configuration, three center functions are offered: All Ports Blocked (APB), Center Open Exhaust (COE), and Center Open Pressure (COP).
Technical Parameters:
| Brand |
IMI Norgren |
| Operating Pressure |
1.5 To 8 Bar |
| Valve Type |
Solenoid Actuated Spool Valve |
| Medium |
Compressed Air, Filtered To 40 μm, Lubricated Or Non-lubricated |
| Functions |
3/2 NO, 3/2 NC, 5/2, 5/3 APB, 5/3 COE, 5/3 COP |
| Series |
VCB22 |
Applications:
The Norgren VCB22 series solenoid valves are extensively utilized across a variety of industrial sectors. Their reliable performance and versatility make them ideal for numerous automation applications.
In the packaging machinery industry, these valves provide essential pneumatic actuation control for processes such as food packaging, carton forming, and filling lines. This ensures efficient and precise operation in packaging systems.
Within automotive manufacturing, the VCB22 series plays a crucial role in air circuit switching for welding fixtures, assembly lines, and robotic workcells. This contributes to streamlined production and enhanced automation.
The food and beverage sector benefits from these solenoid valves through automated control capabilities for filling equipment, labeling machines, and sorting systems, facilitating increased productivity and hygiene compliance.
Textile machinery also incorporates the VCB22 series for pneumatic drives used in looms, dyeing apparatus, and fabric handling lines, supporting smooth operation in textile manufacturing processes.
In chemical and pharmaceutical industries, the valves are employed for pneumatic isolation within process control fluid circuits. It is important to verify media compatibility to ensure safe and effective use in these sensitive environments.
Electronics and semiconductor manufacturing utilize these valves for precision pneumatic control in cleanroom equipment, PCB assembly, and inspection systems, where accuracy and cleanliness are paramount.
For general industrial automation, the Norgren VCB22 series offers directional control for tasks such as machine loading and unloading, conveyor operations, lifts, and rotary tables, enhancing overall system efficiency.
The valves are also suitable for NAMUR applications, allowing for direct mounting on pneumatic actuators, including cylinders and control valves, in accordance with NAMUR standards.
Lastly, manifold systems benefit from the ability to install multiple valves centrally using sub-bases, enabling integrated piping solutions and simplified maintenance.
Support and Services:
Norgren Solenoid Valves are engineered to deliver reliable and efficient performance in a wide range of industrial applications. Our technical support team is dedicated to providing comprehensive assistance to ensure optimal operation of your solenoid valve.
We offer expert guidance on product selection, installation, troubleshooting, and maintenance to maximize the lifespan and performance of your Norgren solenoid valves. Our services include detailed product documentation, application support, and access to firmware and software updates where applicable.
For complex applications, our specialists provide tailored solutions to meet your specific requirements. We also offer training sessions and workshops to help your team understand the best practices for using and maintaining Norgren solenoid valves.
Regular maintenance and timely servicing are critical to the reliable operation of solenoid valves. We provide comprehensive service programs including inspection, repair, and replacement of components to minimize downtime and maintain system efficiency.
Choose Norgren for innovative solenoid valve technology supported by a responsive and knowledgeable technical service team committed to your success.
Packing and Shipping:
The Norgren Solenoid Valve is carefully packaged to ensure maximum protection during transit. Each valve is individually sealed in anti-static, moisture-resistant packaging to prevent damage from environmental factors. The product is then placed in a sturdy, cushioned box designed to absorb shocks and vibrations.
For shipping, Norgren Solenoid Valves are securely packed in reinforced cartons with clear labeling for easy identification. Multiple units are arranged to minimize movement and prevent impact damage. All shipments include appropriate documentation and handling instructions to guarantee safe and timely delivery to the customer.
