Product Description:
The NORGREN 18D Series (Model 0880 / 0881) is an electro-mechanical pneumatic pressure switch that has been extensively proven in industrial automation applications. It functions as a diaphragm-actuated pressure monitor and is suitable for tasks such as pressure alarm, interlock, and loop control. This series is designed to operate across a wide pressure range from vacuum up to 30 bar, offering multiple choices for port connections, including G1/4, 1/4 NPT, and flange mounting options.
Users can select between two types of electrical connections: the DIN EN 175301-803 Form-A and M12×1 IEC 947-5-2 connectors. Additionally, LABS-free variants and special brass-body versions tailored for water service are available, making these switches suitable for neutral gases, liquids, and water media applications.
The switch features a gold-plated contact microswitch that meets UL and CSA certifications, ensuring intrinsically safe operation. It offers high durability with resistance to vibrations up to 15 g and a mechanical service life of up to 10 7 switching cycles, maintaining excellent repeatability. The standard housing is made of aluminum alloy, while brass housings are available for water-specific models. Seal options include NBR and FPM, with the maximum ingress protection rating reaching IP67, which is ideal for harsh industrial environments.
When the system pressure reaches the preset threshold, the SPDT micro-switch outputs an electrical signal that can be used for machine interlock, alarms, or on-off control in pneumatic machines, hydraulic circuits, and water treatment equipment.
Note: It is recommended that set-points be set within the middle of the pressure range. The pressure should never exceed the rated pressure indicated on the nameplate. Inductive loads require spark-quenching protection circuits. Connectors are sold separately; DIN or M12 plugs are not included.
Features:
Experience the authentic quality of NORGREN IMI with the complete 18D‑0880 range. This product line offers a variety of pressure ranges and port options to suit diverse application requirements.
The diaphragm-operated devices function efficiently within an operating pressure range of -1 to 30 bar (-14 to 435 psi), and can withstand a maximum over-pressure of 80 bar for enhanced durability.
Equipped with a gold-plated contact micro-switch that has both UL and CSA approvals, these switches boast an impressive mechanical life of up to 10 7 switching cycles, ensuring long-lasting performance.
Designed for high vibration resistance up to 15 g, the switches also support intrinsically-safe operation, making them reliable in demanding environments.
The ingress protection ratings are IP65 for DIN connectors and IP67 for M12×1 connections, safeguarding the devices against dust and water ingress.
They are compatible with neutral, non-flammable gases and liquids. For water service applications, there is a dedicated brass body available. Moreover, these products can handle media viscosities up to 1000 mm²/s.
The SPDT switch output comes with fixed hysteresis and allows for unrestricted mounting positions, providing flexibility in installation.
Seal materials such as NBR and FPM are selectable, with LABS-free versions also available to cover a full vacuum range, catering to various sealing needs.
Two electrical interface options are offered: DIN EN175301-803 Form-A and M12×1 IEC947-5-2, ensuring compatibility with different system configurations.
Technical Parameters:
| Actuation |
Diaphragm Type |
| Brand |
IMI NORGREN |
| Max Over‑pressure |
80 Bar |
| Series |
18D Series, 0880 / 0881 Model Family |
| Operating Pressure |
-1 … 30 Bar |
| Hysteresis |
Fixed Switching Differential |
Applications:
This system provides reliable pressure monitoring and alarm functions tailored for industrial pneumatic automation setups. It ensures continuous oversight to maintain optimal operational safety and efficiency.
In addition, it offers interlock protection specifically designed for compressors and vacuum pumps, preventing equipment damage by coordinating their pressure boundaries effectively.
For hydraulic fluid power systems, accurate pressure signal feedback is available, enabling precise control and diagnostics to enhance system performance and reliability.
The equipment also supports water-treatment and water-supply applications, featuring brass variants suitable for water-service environments to ensure durability and corrosion resistance.
Pressure detection capabilities are integrated into packaging machinery, machine tools, and conveyor equipment, providing essential data to maintain operational accuracy and avoid downtime.
Over-pressure alarms and machine start-stop control functions safeguard industrial fluid pipelines, preventing hazardous pressure conditions and ensuring smooth process management.
Finally, the system includes vacuum monitoring and control functionality for general-purpose machinery, helping maintain appropriate vacuum levels across diverse industrial applications.
Support and Services:
Norgren offers comprehensive Product Technical Support and Services for its Solenoid Valve products to ensure optimal performance and customer satisfaction. Our expert team is available to assist with product selection, system integration, troubleshooting, and maintenance advice. We provide detailed technical documentation, including datasheets, installation guides, and operation manuals to support your application needs. Additionally, Norgren offers repair and refurbishment services to extend the lifecycle of your solenoid valves, along with calibration and testing to guarantee reliability and compliance with industry standards. For customized solutions, our engineering support can help tailor solenoid valve configurations to meet specific operational requirements. Trust Norgren for professional support and service throughout the entire lifecycle of your solenoid valve products.
Packing and Shipping:
The Norgren Solenoid Valve is carefully packaged to ensure maximum protection during transit. Each valve is enclosed in a sturdy, custom-designed box with shock-absorbing materials to prevent damage from impact or vibration. The packaging includes clear labeling with product details, handling instructions, and safety information to facilitate proper storage and handling.
For shipping, the Norgren Solenoid Valve is securely placed in protective cartons and palletized when necessary to maintain stability. We utilize reliable courier services that provide tracking and timely delivery to ensure the product arrives in excellent condition. Special shipping requirements can be accommodated upon request to meet specific customer needs.
