T70C3800 Repair Kit IMI Norgren Quick Exhaust Valve Seal Maintenance Spare Parts

Product Description:

The NORGREN T70 Series Quick Exhaust Valve is a top-tier inline poppet-type pneumatic valve designed specifically for industrial compressed-air systems. This high-performance valve enables rapid discharge of air directly from pneumatic cylinders and air reservoirs, eliminating the need for exhaust air to pass back through control valves. As a result, it significantly enhances cylinder operating speed, reduces response cycle time, and increases the overall efficiency of pneumatic systems.

This series is available with both G (BSPP) and NPT thread options, accommodating port sizes such as G1/8, G1/4, G3/8, and G1/2. The T70 valves are characterized by their compact inline-mount construction, delivering stable high-flow performance along with long-lasting operational reliability.

Manufactured by IMI Norgren, the T70 Series is widely utilized in factory automation pneumatic circuits around the world. To support maintenance and prolong the service life of these valves, spare repair kits are also available, facilitating easy on-site repairs.

Features:

The product features a direct quick exhaust system designed for air cylinders and air tanks, which significantly enhances the speed of cylinder movement. This mechanism ensures faster response times and improved operational efficiency.

It utilizes a poppet-valve structure with a simple and compact inline-mount design, making installation straightforward and convenient. This design minimizes space requirements while maintaining reliable performance.

The device operates effectively across a wide pressure range from 0.5 to 10 bar (7 to 145 psi), providing versatility for various pneumatic applications. It is compatible with filtered compressed air and supports both lubricated and non-lubricated air supplies.

With a broad temperature tolerance ranging from -20℃ to +80℃ (-4℉ to +176℉), this product is suitable for use in diverse environmental conditions without compromising functionality.

Constructed from robust materials, the housing features an aluminium and zinc alloy body and cover, along with NBR nitrile rubber seals that offer excellent wear resistance, ensuring durability and long service life.

Several thread options are available, including ISO-G parallel thread and NPT thread, covering a full range of port sizes from G1/8 to G1/2. This flexibility facilitates easy integration into existing systems.

Furthermore, the product delivers high flow performance with low-pressure loss, optimizing system efficiency. Spare repair kits are also provided to support maintenance and reduce downtime in the field.

Technical Parameters:

Applications:

The NORGREN T70 quick exhaust valves are extensively utilized in industrial automation pneumatic systems to enhance the speed of cylinder retraction and extension. These valves play a crucial role in improving the efficiency and responsiveness of pneumatic operations across various industries.

Typical applications include packaging machinery and printing equipment, where rapid exhaust is essential for maintaining high production rates. They are also commonly found in conveyor and material-handling systems, facilitating smoother and faster movements.

In the automotive sector, NORGREN T70 valves are employed on assembly lines and machine tools, contributing to streamlined manufacturing processes. Additionally, these valves serve important functions in textile machinery and robotic pneumatic actuators, ensuring precise and swift actuation.

Beyond these, the valves are widely applied in general factory automation, as well as in pneumatic fixtures and clamping equipment. They are also integral components within pneumatic presses, sorting mechanisms, and processing machinery.

Important Warning: These valves are intended only for use with industrial compressed-air systems. Do not exceed the specified pressure and temperature limits. For applications involving other media or specialized systems, please contact Norgren technical support for guidance.
