Product Description:
The SMC CQ2 Series seal kits are authentic replacement parts specifically designed for the maintenance and refurbishment of CQ2A, CDQ2A, CQ2B, and CDQ2B series compact pneumatic cylinders. These kits ensure that your cylinders continue to operate smoothly and efficiently.
Each seal kit includes a full set of essential sealing components, such as the piston seal, rod seal, and tube gasket. All parts are made from high-quality NBR (nitrile rubber), which guarantees dependable performance and extends the lifespan of the seals under various working conditions.
These seal kits come in bore sizes ranging from 12mm up to 100mm. Customers can order the appropriate kit that matches the exact bore size of their pneumatic cylinder, ensuring a perfect fit every time. Using these kits helps restore the cylinder’s sealing effectiveness, prevents any air leaks, and maintains optimal force and response speed for the pneumatic system.
Moreover, the SMC CQ2 seal kits are compatible not only with the standard CQ2 series compact cylinders but also with models designed to resist lateral loads. By opting for these seal kits, users can achieve cost-effective maintenance without the need to replace the entire cylinder assembly, saving both time and expense.
Features:
The Complete Seal Kit comprises a piston seal, rod seal, and tube gasket, providing everything needed for a comprehensive cylinder overhaul. This all-in-one solution ensures that every critical sealing component is replaced to maintain optimal cylinder function.
Crafted with genuine SMC quality, each seal kit is manufactured according to precise SMC specifications. This guarantees an exact fit and dependable sealing performance, enhancing the reliability of your pneumatic systems.
Utilizing high-quality nitrile rubber (NBR) material, the seals deliver exceptional resistance to wear and compression set, as well as resilience against industrial air media. This durable material choice extends the service life of the seals under demanding operating conditions.
The kit supports a broad range of bore sizes, including 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 80mm, and 100mm, making it adaptable to various cylinder dimensions and applications.
Designed for compatibility with multiple cylinder models such as CQ2A, CDQ2A, CQ2B, CDQ2B, CQ2Z, CQP2, and other members of the CQ2 family, this seal kit simplifies maintenance across several equipment lines.
By replacing worn-out seals, the kit restores the cylinder’s original performance characteristics, including force, speed, and cushioning. This renewal helps maintain system efficiency and prolongs the lifespan of your cylinders.
Quick and straightforward seal replacement reduces downtime, minimizing interruptions to production processes while avoiding the need for expensive cylinder replacements.
This maintenance solution is cost-effective, offering a fraction of the price of purchasing a new cylinder while ensuring comparable sealing quality and reliability.
Additionally, the seal kit is RoHS compliant, meeting stringent environmental and safety requirements for industrial usage.
The seals are designed to operate effectively over a wide temperature range from -10°C to +70°C, ensuring consistent performance in various working environments.
Technical Parameters:
| Bore Sizes Available |
12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm |
| Compatible Cylinder Series |
CQ2A, CDQ2A, CQ2B, CDQ2B, CQ2Z, CQP2, CQ2□S |
| Brand |
SMC |
| Kit Contents |
Piston Seal, Rod Seal, Tube Gasket |
| Product Type |
Cylinder Seal Kit / Repair Kit |
| Seal Material |
NBR |
| Series |
CQ2 |
| Operating Temperature |
-10°C to +70°C |
Applications:
Applications of Compact Pneumatic Cylinder Maintenance
In the field of factory automation , maintaining compact pneumatic cylinders is essential for the smooth operation of automated production lines. Regular upkeep ensures minimal downtime and optimal performance in these systems.
When it comes to material handling , the repair and maintenance of cylinders used in conveyors, pick-and-place units, and various handling systems help maintain efficiency and reliability throughout the process.
The packaging machinery sector relies heavily on pneumatic cylinders, where seal replacement is a crucial task in cylinders used within packaging and filling equipment to prevent leaks and maintain consistent operation.
In the domain of electronic component manufacturing , precise assembly equipment depends on well-maintained cylinders to ensure accuracy and repeatability in production.
The automotive assembly industry requires prompt repair and servicing of compact cylinders used in assembly tools and testing fixtures, which are vital for maintaining quality and productivity.
Food and beverage processing lines utilize pneumatic cylinders extensively in both processing and packaging stages, where regular maintenance helps uphold hygiene standards and operational efficiency.
Generally, in any application involving pneumatics , reliable sealing and performance restoration of compact cylinders are critical for ensuring long-term functionality and reducing maintenance costs.
